HTS-608 series 8 serial port serial port server, according to the needs of users, provide a variety of different changes and combinations, such as optional DC 9V/12V/24V/48V power supply mode, in addition to the standard RJ45 serial port form, can also be equipped with terminal serial port form, but also according to the need to form a variety of RS-232, RS-485, RS-422 different combinations.You can also choose the Desk model or the standard 1U Lite model.

Desktop type, small size.Rack type, easy installation

High performance processor, large memory capacity

Parameter configuration can be carried out remotely by Web browser through the network

Built-in 15kV ESD surge protection for all serial ports

Intuitive Chinese menu setting interface makes installation and configuration easier

RS-232/422/485 serial port can be combined flexibly, and type conversion completely depends on software Settings

Multi-level power supply design, to meet the needs of different on-site environment power supply

Can provide customized products, terminal type serial interface, terminal type power interface, convenient wiring

Under Windows, COM port is driven, and it can support up to 6 hosts to open the same serial port at the same time

Support TCP and UDP Socket, each serial port can support 6 different session mode

Unix and Linux fixed TTY drives are provided

Support PPP/SLIP dial-in and dial-out

Support for TTY, a character terminal connected to the banking system

Transparent transmission mode is adopted, and users do not need to know the complex TCP/IP protocol

AES encryption function (optional), the user's data to obtain reliable security.

CPU: 32 bit 100MHz

Ethernet speed: 10/100 Mbps adaptive, and supports manual energy setting.

Communication mode: 10M half duplex and 10M full duplex, 100M half duplex and 100M full duplex

Port protection: 15kV electromagnetic isolation

Serial ports: 8 RS-232/422/485 serial ports

Port connection: RJ45 Male to RS-232/RS-485 and RJ45 to Ethernet

Signal: RS-232 TXD, RXD, RTS, CTS, DTR, DSR, DCD, GND

RS-422 Tx+, Tx-, Rx+, Rx-, GND

RS-485 (4-line) Tx+, Tx-, Rx+, Rx-, GND

RS-485 (2-line) Data+, Data-, GND

Serial communication parameters data bits: 5, 6, 7, 8

Verify: None, Even, Odd, Space, Mark

Stop bits: 1, 1.5, 2

Flow control: RTS/CTS, XON/XOFF

Speed: 300 BPS to 230.4Kbps

Protocol: DHCP, TELNET, TCP, UDP, IP, ICMP, ARP

Real COM driver: Windows NT/2000/XP/ Vista /7

Fixed TTY drivers: SCO Unix, Linux

Configuration: Telnet or Web interface

Power input: 220V AC adapter or DC power supply

(optional)

Operating humidity: 5 to 95% Storage temperature: -20 to 85 °C
