Лазерный дальномер лазерный измерение лазером возможностью погружения на глубину до 30 м клейкие ленты


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-17-2025 0.29 $* 0.64 $*
Aug-17-2025 0.88 $* 0.59 $*
Jul-17-2025 0.97 $* 0.7 $*
Jun-17-2025 0.4 $* 0.67 $*
May-17-2025 0.60 $* 0.78 $*
Apr-17-2025 0.62 $* 0.84 $*
Mar-17-2025 0.17 $* 0.91 $*
Feb-17-2025 0.96 $* 0.34 $*
Jan-17-2025 0.48 $* 0.35 $*

Характеристики



Hot sale




Product images


Specification:

1.The most advanced technology of double color & material integrative mould, strong and firm;

2.Advanced antireflection LCD, clear display interface in field;

3.0.8m ultra-short event dead zone, easy to test optical fiber jumper;

4.Automatic & manual test function;

5.Automatic detection of the communication light signal;

6.Touch screen and keyboard operation;

7.Two USB interfaces: can connect to the external U disk, or communicate with PC through SyncActive software;

8.Support Bellcore GR196 and SR-4731 file format;

9.Intelligent indication of battery capacity, alarm when the battery is running out;

10.WinCE window operation system, Chinese/ English operation interface;

11.Large capacity lithium battery to support over 10 hours of operation, suitable for long-time filed work;

12.Built-in visible fault locator (VFL) function;

13.The OTDR optical output connectors are exchangeable, so it is more convenient to clean the end surface;

14.Application software on-line upgrading, no need to return back to factory.



     Model
OTDR
Display
5.7 inch color LCD with touch
Dynamic Range
32/30dB
Distance range
400m/800m/1.6Km/3.2Km/6.4Km/16Km/32Km/64Km/128Km/256/512Km
Measuring Pulse Width
5ns/10ns/30ns/100ns/275ns/500ns/1000ns/5000ns/10000ns/20000ns
Ranging Accuracy
±(1m+Sampling interval+0.005%×Test distance)
Degree of Linearity
±0.05dB/dB
Resolution Ratio Loss
0.001dB
Event Dead Zone
0.8m
Waveform Data Storage
≥1000
Interface Type
FC/PC(Replaceable SC,ST)
Communication Interface
USB mini-USB 10M/100M Ethernet
VFL Output
≥5mW
OPM
Wavelength range: 1200nm~1650nm, Power range: -50dBm~+26dBm
Stable Light Source
1310/1550nm: -5dBm, CW (270Hz, 1K270Hz, 2K270Hz)
Power Supply mode
Output: 19V, 1.31A ; Lithium battery:7.4V 6300mAh
Operating Temperature
-5°C~50°C
 Storage   Temperature
-20°C~70°C
Relative Humidity
0~95°C Non condensation
Weight
1.5kg
Dimensions
215mm×150mm×70mm


Product Picture








Certifications




Our factory






Packing & Delivery


We hope goods arrive on time, but since this is an international delivery, shipping time will be highly depended on the deliver company and local customs/duties. We will try our best. Thank you for your kindly understanding.






Contact us



Cara


Phone number:+8613721026446(whatsapp)
Email:xctxsales7@163.com


If you give a start for our business relations, we will provide satisfactory product and services for you. Welcome to your inquiry!
