Промышленный кольцевой вентилятор для сушки бутылок 7500 Вт 10
- Категория: Воздуходувка >>>
- Поставщик: Dongguan,Foersheng,Intelligent,M&E,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 875.60 $* | 893.18 $* |
| Jul-20-2025 | 710.96 $* | 724.93 $* |
| Jun-20-2025 | 861.86 $* | 878.97 $* |
| May-20-2025 | 854.60 $* | 871.62 $* |
| Apr-20-2025 | 682.74 $* | 696.40 $* |
| Mar-20-2025 | 841.39 $* | 858.94 $* |
| Feb-20-2025 | 834.44 $* | 851.8 $* |
| Jan-20-2025 | 827.22 $* | 844.6 $* |
Характеристики
Product Paramenters
Product Name | 7500W 10HP Industrial Ring Blower For Bottle Drying System | ||||
Features | 100% Copper Wire Motor,High Quality Bearings,Low Noise,Energy-saving, Big Airflow,More Duable,More Safety. | Frequency | |||
Model | GHBH 010 36 1R8 |
Stage | single |
Phase | three |
Frequency | 50Hz |
Rated Power | 7.5kW |
Rated Voltage | 345-415△/600-690Y(V) |
Rated Current | 16.7△/9.6Y(A) |
Max Airflow | 530m³/h |
Max Vacuum | -320mbar |
Max Pressure | 430mbar |
Sound | 70db(A) |
Weight | 66kg |
Products Description
High efficiency motor； IP55 & Insulation class H； Built-in Thermal Protector(PTC)； High Temperature-Resistance bearing； Special customized blower and OEM available； 24 months warranty and long-term technical support； CCC, CE, SGS, TUV, RoHS, ISO9001 certification approved. | ||
The above data is obtained based on laboratory testing. Actual applications will have a deviation of ±10% depending on the altitude, air density, humidity, temperature, etc.!
More Applications:
Blowing | Suction |
Plastic processing | Vacuum lifting and clamping system |
Plating Equipment | Packaging/printing/labeling/paper/glass machines |
Biogas/natural gas transportation | Bag/bottle/hopper filling system |
Water/Sewage/septic-tank Treatment | CNC/woodworking router |
Acquaculture/swimming pool aeration | Foam molding system |
Air knives washing/drying machines | Cutting Machine |
Pneumatic conveying system | Ducted Vacuum Systems |
Food and vegetable processing | Dental Equipment |
Textile industry | Central Cleaning system |
Soil remediation | Waste suction machine |
ultrasonic cleaning line | Gas analysis system |
Tunnel air evacuation | Vacuum glove box |
Wood machine-Chip Removal | auto feeding Hopper/auto Hopper Loader |
Paper / Film Scrap Collection | Clinic suction systems |
INSTRUCTIONS
1. It should be placed in a relatively stable place, and the surrounding environment should be clean, dry and ventilated.
2. The direction of rotation of the impeller must be consistent with the direction of the pointed tip marked on the fan cover.
3. When working, the working pressure should not be greater than 8 kPa, so as to avoid excessive heat generation of the air pump and damage to the air pump caused by motor overcurrent.
4. It is strictly forbidden for solid, liquid and corrosive gas to enter the pump body.
5. The filters and silencers at both ends of the air inlet and outlet should be cleaned in time according to the situation to avoid clogging and affecting use.
6. The external connection of the air inlet and outlet must be connected by a hose (rubber tube, plastic spring tube).
PRECAUTIONS
1. Flat washers and spring washers must be used to tighten the screws.
2. It is best to use rubber buffer rubber to bear the weight of the air pump, especially the high-power air pump, which is indispensable.
3. For some occasions that require noise, a silencer can be installed to reduce the noise (generally down, about 5 dB), the silencer is installed at the end of the inlet duct or outlet duct.
4. For some occasions with high requirements for noise, you can add a layer of silencer cotton according to the conditions of the machine itself to meet the noise requirements on site. For details, please consult our customer service.
5. When using silencing cotton to silence the sound, pay attention to the distance between the air pump and the box, pay attention to the ventilation and heat dissipation of the air pump, and pay attention to using rubber cushioning to bear the weight of the air pump. According to the picture, you need to consult customer service.
6. The air inlet and outlet of the air pump For pipe connection, hose connection should be used to isolate vibration.
1. It should be placed in a relatively stable place, and the surrounding environment should be clean, dry and ventilated.
2. The direction of rotation of the impeller must be consistent with the direction of the pointed tip marked on the fan cover.
3. When working, the working pressure should not be greater than 8 kPa, so as to avoid excessive heat generation of the air pump and damage to the air pump caused by motor overcurrent.
4. It is strictly forbidden for solid, liquid and corrosive gas to enter the pump body.
5. The filters and silencers at both ends of the air inlet and outlet should be cleaned in time according to the situation to avoid clogging and affecting use.
6. The external connection of the air inlet and outlet must be connected by a hose (rubber tube, plastic spring tube).
PRECAUTIONS
1. Flat washers and spring washers must be used to tighten the screws.
2. It is best to use rubber buffer rubber to bear the weight of the air pump, especially the high-power air pump, which is indispensable.
3. For some occasions that require noise, a silencer can be installed to reduce the noise (generally down, about 5 dB), the silencer is installed at the end of the inlet duct or outlet duct.
4. For some occasions with high requirements for noise, you can add a layer of silencer cotton according to the conditions of the machine itself to meet the noise requirements on site. For details, please consult our customer service.
5. When using silencing cotton to silence the sound, pay attention to the distance between the air pump and the box, pay attention to the ventilation and heat dissipation of the air pump, and pay attention to using rubber cushioning to bear the weight of the air pump. According to the picture, you need to consult customer service.
6. The air inlet and outlet of the air pump For pipe connection, hose connection should be used to isolate vibration.
Product packaging
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
GOORUI is now becoming a world-class manufacturer of premium side channel blowers and accessories. Our programme of continuous investment and innovation places us at the forefront of blowers manufacture. Goorui's philosophy is to create a partnership with our clients. We are committed to providing you with all the resources you may require with regard to your systems. Our advantages come from our efficient size: we provide the units at a very competitive price.
Enterprise Scene
Dongguan Foersheng Electric&Mechanic Co.Ltd. World leading supplier of vacuum equipment with designing.producing and marketing experienee for 18 years.Which is subordinate to Hong kong Fenglisheng Group Company Limited,located in the most famous world manufacture city.Dongguan City.to be an industrial manufacture enterprise with its own proprietary intellectual property rights.
Production Workshop
Test certificate include ISO9001 ,CE,RHOS,"Chinese trademark certificate","German trademark certificate","Dongguan city Energy saving Company","Dongguan city patent foster company ","Dongguan city high tech no logy privatization company","Guangdong provice high technology privatization company".
Goorui regenerative,once come to Chinese market.deriverted from German,precise to the max,with quiet,stable performanee and long working life.
In 2006.the first double stage side channel blower borned in China largely improved its air flow and pressure.
Branch office in mainland China:Beijing,Shanghai,Shandong,Sichuan.Net-work in the world
Goorui regenerative,once come to Chinese market.deriverted from German,precise to the max,with quiet,stable performanee and long working life.
In 2006.the first double stage side channel blower borned in China largely improved its air flow and pressure.
Branch office in mainland China:Beijing,Shanghai,Shandong,Sichuan.Net-work in the world
wide,European,Middle est,merica,products are exported to 100 different countries andaeras.
Fullfill responsiblities of enterprise,archive worldwide brand,FLS with strategic objestive "archive world wide leading vacuum brand".
Fullfill responsiblities of enterprise,archive worldwide brand,FLS with strategic objestive "archive world wide leading vacuum brand".
Our Service
Marketing Service
* 100% tested CE certified blowers.
* Special customized blowers(ATEX blower,belt-driven blower) for special industry.Like gas transportation,Medical industry...
* Professional advice for model selection and further market development.
After-sale Service
* Experienced suggestion for blower installation and use.
* 18 months warranty.
* Long-term technical support.
* 100% tested CE certified blowers.
* Special customized blowers(ATEX blower,belt-driven blower) for special industry.Like gas transportation,Medical industry...
* Professional advice for model selection and further market development.
After-sale Service
* Experienced suggestion for blower installation and use.
* 18 months warranty.
* Long-term technical support.
FAQ
Q1：What is the warranty of your machine?
A1：18 months, any product itself question,you can contact with us.
Q2：What is the material of your machine , is oil free?
A2：Our machine is aluminum alloy, motor is 100% copper coil , of course, we are oil free.
Q3：How to operate your machine?
A3：Connect with wire, and turn on the power, so you can use it directly, about the wiring method, we will tell you how to do according to your voltage, so at first , you need to tell us your voltage and phase,its important.
Q4：You are trading company or manufacture?
A4：We have our own factory and international department,We produce and sell all by ourselves.
Q5：How to guarantee the quality and after sales service of your goods?
A5:1).Strict detection during production.
2).Strict sampling inspection on products before shipment and intact product packaging are insured.
3).Follow up and adopt customers feedbacks in a timely manner after sales.
A1：18 months, any product itself question,you can contact with us.
Q2：What is the material of your machine , is oil free?
A2：Our machine is aluminum alloy, motor is 100% copper coil , of course, we are oil free.
Q3：How to operate your machine?
A3：Connect with wire, and turn on the power, so you can use it directly, about the wiring method, we will tell you how to do according to your voltage, so at first , you need to tell us your voltage and phase,its important.
Q4：You are trading company or manufacture?
A4：We have our own factory and international department,We produce and sell all by ourselves.
Q5：How to guarantee the quality and after sales service of your goods?
A5:1).Strict detection during production.
2).Strict sampling inspection on products before shipment and intact product packaging are insured.
3).Follow up and adopt customers feedbacks in a timely manner after sales.
