1. Excellent thermal conductivity and conductivity. 2. Low linear expansion coefficient, good thermal stability and thermal shock resistance. 3. Chemical resistance is not easy to react with most metals. 4.In high temperature in most of the copper base tire body sintering( temperature above 800 ºC) intensity increases with temperature rise 5. Good lubrication and abrasion resistance. 6. Easy to process, good mechanical processing performance, can be made into a complex shape, high precision mold.
Application: 1. Brass continuous casting mould.
2. Red copper continuous casting mould 3. Continuous casting mould for jewelry of gold, silver, platinum, etc. 4. Steel and stainless steel continuous casting mould. 5. Mould for glass forming. 6. Sintering mold and other diamond sintering molds. By the shape of the cast product, it is divided into round bar mould, hollow tube mould, and shaped mould.
Indicator&Size
We have our own independent production line and R & D team, according to customer drawings requirements, the production of different grades of different sizes of the mold.
Density
Resistivity
Thermal conductivity(100℃)
Shore hardness
Flexural strength
Compressive strength
1.6-1.9g/cm³
8-15μΩm
90-140W/m.k
45-80HSD
40-85Mpa
70-175Mpa
