Характеристики
![_01.jpg]()
![plug-in_GPRS_prepaid_three_phase_electricity_meter.jpg]()
![plug-in_GPRS_prepaid_three_phase_electricity_meter.jpg]()
![plug-in_GPRS_prepaid_three_phase_electricity_meter.jpg]()
![plug-in_GPRS_prepaid_three_phase_electricity_meter.jpg]()
![plug-in_GPRS_prepaid_three_phase_electricity_meter.jpg]()
![]()
Technical Parameters
|
Nominal Voltage
|
3*230V
|
Working Voltage Range
|
70%~120%Un
|
Nominal Frequency
|
50-60Hz
|
Basic Current (Ib)
|
5A
|
Maximum Current (Imax)
|
80A
|
Starting Current (Ist)
|
20mA
|
Active Energy Constant
|
1600imp/kWh
|
Active Energy Accuracy
|
Class 1.0
|
Reactive Energy Accuracy
|
Class 2.0
|
Power Consumption in Voltage Circuit
|
<2W <8VA
|
Power Consumption in Current Circuit
|
<1VA
|
Operation Temperature Range
|
-25℃-70℃
|
Storage Temperature Range
|
-40℃-85℃
|
Electro Magnetic Compatibility
|
AC Insulation Strength
|
4kV at 50Hz during 1min
|
Impulse voltage 1.2/50 us mains connections
|
8kV
|
Electrostatic Discharges
|
Contact discharge
|
8kV
|
Air discharge
|
16kV
|
Electromagnetic RF Field
|
27MHz-500MHz
|
10V/m
|
100KHz-1GHz
|
30V/m
|
Fast transient burst test
|
4kV
|
Mechanical requirements
|
Meter shell Water proof protection Rate
|
IP54
|
Protection
|
Class II
|
Meter Dimensions
![1.jpg]()
Basic Functionality
|
Function
|
Details
|
Prepayment
|
STS Standard, recharge by input 20digits TOKEN
|
Low credit alarm
|
Alarm value can be set by inputting corresponding TOKEN
|
Prepaid and post-paid switch
|
Meter can be switch to prepaid mode or post-paid mode
|
Load control function
|
Meter can be programmed for load control threshold, If the current power is more than threshold. The meter will cut off user load.
|
Event recording
|
Meter can record the tamper event, open cover event, purchase event and TOKENS.
|
Self-testing
|
Meter has a self-test function, it can test LCD and relay etc. and report the result directly
|
Anti-tamper
|
Meter will automatically close the valve after detection of magnetic field and open cover event
|
TOU Tariff
|
TOU Tariff can be set by inputting corresponding TOKEN
|
Overdraft Collection
|
Electricity Overdraft can be collected day by day or month by month
|
Communication
|
The meter is available with AMI system through LORA RF or Bluetooth 4.0 on request
|
Information Inquiry
|
Consumer could check the data like Credit Remain, Total Purchased and Total Credit by input the short code
|
Liquid Crystal Display
|
999999.99
|
![.jpg]()
![_08.jpg]()
![_09.jpg]()
![_10.jpg]()
![_11.jpg]()
Q1.Can l have sample for relay?
A:Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about lead time?
A.Sample needs 3-9 days, mass production time needs 1-2 weeks for order quantity more than.
Q3. Do you have any MOQ limit for relay order?
A: Low MOQ,1pc for sample checking is available.
Q4. How do you ship the goods and how long dose it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. lt usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for relay?
A:Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6.Is it ok to print my logo on relay?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
