The diesel mine dumper truck is our main product, The loading capacity of it is 5 ton. And this diesel mine dumper truck has the characteristics of strong power, strong loading capacity, long working hours, and small requirement for road condition, at the same time this vehicle is driven by diesel, so the power is strong . Which are deeply loved by customers from home and aboard. Upon this, the dumper can be widely used in brick factory, mine factory, construction site and other places with transportation demand.
Specification
5 ton wheel dumper truck
Engine model
CHANGCHAI 490 50HP
Gearbox type
NANJING 130 (4+1)range shift
Transfer case
2120
Front axle
130 Drive steering front axle
Rear axle
Isuzu drive rear axle
Car body
2400*1500*450mm
Steel plate thickness
Bottom 6mm edge 4mm
Tyre model
700-16
Frame
160*60*6mm
Hydraulic cylinder
110*900mm(Diameter*Stroke)
Number of spring plates
Front:7 Rear:8+6
Braking method
Air brake
Steering method
Hydraulic steering gear
Exhaust treatment
Water treatment
Dumper size
4000*1500*1300mm
Man-machine height
1800mm
Gear mode
Gear line
Diesel engine
Changchai 490 diesel engine, 50 horsepower, powerful power and excellent quality.
Shaft drive
It adopts shaft transmission to connect the body, with simple structure and convenient driving.
It adopts double hydraulic lifter, the force is even, and the lift is stable.
Large-capacity hydraulic oil tank, long use time.
Hydraulic adjustment lever, ergonomic, simple and convenient to operate
Dash board
Real-time display of machine conditions
Drive converter
The driving mode can be selected as rear-wheel drive or four-wheel drive.
Gear lever
Four forward gears and one reverse gear are highly selective.
Detail images
Company Profile
Gongyi jinwang machinery factory is a manufacturer of electric cargo tricycle with well-equipped testing facilities and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in mining industry and other industries.
Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.
FAQ
1. who are we? We are based in Henan, China, start from 2006,sell to Domestic Market(48.00%),Africa(22.00%),Southeast Asia(15.00%),Mid East(7.00%),South Asia(3.00%),South America(2.00%),Eastern Europe(2.00%),Central America(1.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us? electric mini dumper,electric forklift,oil press machine,brick making machine,mucking loader
4. why should you buy from us not from other suppliers? null
5. what services can we provide? Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery； Accepted Payment Currency:USD,CNY; Accepted Payment Type: T/T,L/C,Cash,Escrow; Language Spoken:English,Chinese
