OEM MegaRAID 12 ГБ/сек. 8 порт SATA и SAS LSI 9440-8i надписью
- Категория: Other Computer Parts >>>
- Поставщик: Shenzhen,Cloud,Storage,Information,Consulting,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 214.62 $* | 225.22 $* |
| Aug-18-2025 | 212.43 $* | 223.51 $* |
| Jul-18-2025 | 178.81 $* | 187.6 $* |
| Jun-18-2025 | 209.85 $* | 219.90 $* |
| May-18-2025 | 182.14 $* | 191.23 $* |
| Apr-18-2025 | 205.4 $* | 215.88 $* |
| Mar-18-2025 | 203.1 $* | 213.64 $* |
| Feb-18-2025 | 202.85 $* | 212.7 $* |
| Jan-18-2025 | 200.93 $* | 210.50 $* |
Характеристики
Product Description
Ports:8 internal
Connectors:Two SFF-8643
Storage Interface Support:SAS, SATA, PCIe (NVMe)
Maximum PCIe (NVMe) Direct- Attach Devices:
Two x4, Two x2 (direct-attached only)
Maximum Devices Per Controller*:SAS/SATA: 63
NVMe: 2
Cache Memory:N/A
I/O Processor/ SAS Controller:SAS3408
Host Bus Type:PCIe 3.1 x8
Cache Protection:N/A
Key RAID Data Protection Features:
•64 virtual drive support (32 for 9440)
•DDF compliant configuration on disk (COD)
•S.M.A.R.T support
•Global and dedicated hot spare with revertible hot spare support
-Automatic rebuild
-Enclosure affinity
-Emergency SATA hot spare for SAS arrays
•Enclosure management
-SES (inband)
-SGPIO (sideband)
•DataBolt bandwidth optimizer technology support for compatible expander-based enclosures
Shield state drive diagnostic technology
Patrol read for media scanning and repairing
Physical Dimensions:6.127 in. × 2.712 in.
(155.65 mm × 68.90 mm)
Typical Power:10.05W
Airflow:200 LFM at 55°C
Operating Conditions:Storage:
–45°C to 105°C
5% to 95% non-condensing
MTBF:(Calculated):>3,000,000 hours at 40°C
Operating Voltage:+12V ± 8%; 3.3V ± 9%
Hardware Warranty:3 years
Management Software:LSI Storage Authority (LSA)
StorCLI (command-line interface), HII (UEFI Human Interface Infrastructure)
Regulatory Certifications:FCC、CE、KCC
OS Support:Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD. See www.broadcom.com/support/download-search for details on
Connectors:Two SFF-8643
Storage Interface Support:SAS, SATA, PCIe (NVMe)
Maximum PCIe (NVMe) Direct- Attach Devices:
Two x4, Two x2 (direct-attached only)
Maximum Devices Per Controller*:SAS/SATA: 63
NVMe: 2
Cache Memory:N/A
I/O Processor/ SAS Controller:SAS3408
Host Bus Type:PCIe 3.1 x8
Cache Protection:N/A
Key RAID Data Protection Features:
•64 virtual drive support (32 for 9440)
•DDF compliant configuration on disk (COD)
•S.M.A.R.T support
•Global and dedicated hot spare with revertible hot spare support
-Automatic rebuild
-Enclosure affinity
-Emergency SATA hot spare for SAS arrays
•Enclosure management
-SES (inband)
-SGPIO (sideband)
•DataBolt bandwidth optimizer technology support for compatible expander-based enclosures
Shield state drive diagnostic technology
Patrol read for media scanning and repairing
Physical Dimensions:6.127 in. × 2.712 in.
(155.65 mm × 68.90 mm)
Typical Power:10.05W
Airflow:200 LFM at 55°C
Operating Conditions:Storage:
–45°C to 105°C
5% to 95% non-condensing
MTBF:(Calculated):>3,000,000 hours at 40°C
Operating Voltage:+12V ± 8%; 3.3V ± 9%
Hardware Warranty:3 years
Management Software:LSI Storage Authority (LSA)
StorCLI (command-line interface), HII (UEFI Human Interface Infrastructure)
Regulatory Certifications:FCC、CE、KCC
OS Support:Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD. See www.broadcom.com/support/download-search for details on
Key Features
•Tri-Mode storage interface ports
−SFF-8680 bay
−x1 SAS
−x1 SATA
−x2 SAS (multi-link)
−Two x1 SAS (dual port using MPIO)
− SFF-8639 (U.2) bay
−x2, NVMe
•Supports 12, 6, and 3 Gb/s SAS and 6 and 3 Gb/s SATA data transfer rates
•Tri-Mode storage interface ports
−SFF-8680 bay
−x1 SAS
−x1 SATA
−x2 SAS (multi-link)
−Two x1 SAS (dual port using MPIO)
− SFF-8639 (U.2) bay
−x2, NVMe
•Supports 12, 6, and 3 Gb/s SAS and 6 and 3 Gb/s SATA data transfer rates
