Высокочастотный алмазный инструмент лезвие пилы сегментный сердечник сварочный индукционный медный
- Категория: Welding Equipment >>>
- Поставщик: Ezhou,Aibei,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 48584.24 $* | 49556.68 $* |
| Jul-18-2025 | 39403.7 $* | 40191.12 $* |
| Jun-18-2025 | 47819.9 $* | 48775.32 $* |
| May-18-2025 | 47436.18 $* | 48385.28 $* |
| Apr-18-2025 | 37872.95 $* | 38629.8 $* |
| Mar-18-2025 | 46671.8 $* | 47604.18 $* |
| Feb-18-2025 | 46289.89 $* | 47215.77 $* |
| Jan-18-2025 | 45906.95 $* | 46824.26 $* |
Характеристики
Main characteristics:
1. Adoping MOSFGT and IGBT inverting device, tracking frequency automatically
2. High frequency, heated quickly, its power consumption is only 20%~30% of eletronic tube induction heating machine and other heating style.
3. Security and reliability, the equipment have the secure voltage and it's secure to operate
4. Manual, automatic regulating automatically, it can protect itself from over voltage, over current, lack of water, phase fail, over hot, etc
5. It has no open-fire, noise and pollution, be suit for the environmental protection and fire, improve the image of the company
6. Recommend usage: Weld, forging, hot cooperate, melting, quenching, anneat etc
7. Simple Installation: Power connection, water connection, switch the power on , no need professional work to install.
1. Adoping MOSFGT and IGBT inverting device, tracking frequency automatically
2. High frequency, heated quickly, its power consumption is only 20%~30% of eletronic tube induction heating machine and other heating style.
3. Security and reliability, the equipment have the secure voltage and it's secure to operate
4. Manual, automatic regulating automatically, it can protect itself from over voltage, over current, lack of water, phase fail, over hot, etc
5. It has no open-fire, noise and pollution, be suit for the environmental protection and fire, improve the image of the company
6. Recommend usage: Weld, forging, hot cooperate, melting, quenching, anneat etc
7. Simple Installation: Power connection, water connection, switch the power on , no need professional work to install.
Specification
Model | TLSGP-10KVA | TLGP-30A | TLGP-40A | TLGP-50A |
Input Voltage | 3 phase 380V 50/60HZ | single phase180--250V 50--60Hz | Single phase 180--250V 50--60Hz | Single phase 180--250V 50--60Hz |
Oscillate power max | 25KWA | 8KWA | 10KWA | 12KWA |
Max input current | 1500A | 1200A | 1300A | 1400A |
Oscillate frequency | 30-100KHZ | 30-100KHz | 30-100KHz | 30-100KHz |
Cooling water desire | >0.2MPa 2-5L/Min | >0.2MPa 2-5L/Min | >0.2MPa 2-5L/Min | >0.2MPa 2-5L/Min |
Duty cycle | 100% 40°C | 100% 40°C | 100% 40°C | 100% 40°C |
Dimensions(L*W*H) | 580mm*300mm*460mm | 580mm*300mm*460mm | 580mm*300mm*460mm | 580mm*300mm*460mm |
Net weight | 30kg | 18KG | 20KG | 25KG |
Cable length | 2-6(Meters) | 2-6(Meters) | 2-6(Meters) | 2-6(Meters) |
Suitable for welding | all diamond segment | diamond core bit segment and ø300mm diamond segment | ø300-800mm diamond segment | ø1000-3000mm diamond segment |
Power source | 380V electricity | Home electricity is ok | Home electricity is ok | Home electricity is ok |
Application
![]()
![]()
Company Profile
![]()
Ezhou Aibei Trading Co., Ltd is a Company Located in Ezhou City , A well-know Diamond Tools city, in Hubei Province, China.
We mainly produce diamond Tool, stone concrete cutting blade, diamond segments, diamond profile wheel, grinding pads, polishing pads ,diamond hole drill bit etc.
Our Main Market to Vietnam, India, Pakistan, Russia of federation, Ukraine, Armenia, Georgia, United States of America, South European Countries.
Strict QC inspection , double testing the products, to ensure our customer to get the best and satisfied quality, Young and Energetic Team to service quickly.
Our Advantages
![]()
Recommend Products
![]()
![]()
![]()
![]()
Saw blade welding machine
Core bit welding machine
Induction welding machine
![]()
![]()
![]()
Welding Material
Grinding pads
Diamond polishing pads
Packing & Delivery
![]()
FAQ
1.Are you a Factory ?
Yes, We have our own factory.
2.What is your delivery time?
For sample , if we have stock , we can delivery the same day you place order , for bulk order, delivery time is 7-10 days ranges from quantity
3.What is your payment term?
Our payment can be Bank Transfer, Western Union , Paypal, and pay on Alibaba by Credit card or pay in the bank both are ok .
4.What is your advantages?
1.We have rich experiences about diamond powder , and know how to adjust diamond segment formula according to your different hardness of stone and different cutting machine
2.Strict QC , we double testing the quality before sending out.
Yes, We have our own factory.
2.What is your delivery time?
For sample , if we have stock , we can delivery the same day you place order , for bulk order, delivery time is 7-10 days ranges from quantity
3.What is your payment term?
Our payment can be Bank Transfer, Western Union , Paypal, and pay on Alibaba by Credit card or pay in the bank both are ok .
4.What is your advantages?
1.We have rich experiences about diamond powder , and know how to adjust diamond segment formula according to your different hardness of stone and different cutting machine
2.Strict QC , we double testing the quality before sending out.
