vertical spiral conveyor cooling tower for baking

It has the advantages of stable operation, simple operation, low maintenance cost, etc., and meets the safety and hygienic requirements of the food industry.The layer-by-layer transmission spiral tower is a gear that drives the gears of each layer through a main shaft, and the gears move the mesh belt of each layer to move. Each gear is equipped with an intelligent power transmission to automatically adjust the transmission force.





Advantages

• Double-sided nylon rails run very stably without jamming and turning up.


• Using intelligent transmission technology, the mesh belt of each layer will automatically adjust its pulling force to maintain uniform and consistent transmission force.


• Design various entry and exit directions according to the user's production site, such as low in and high out (lower in and out), high in and low out (up and down), two in two out, three in and three out, and oval.


• Safe and hygienic, the conveyor belt is high-strength food-grade plastic, which is wear-resistant, corrosion-resistant, easy to clean, does not stick to materials, does not damage the appearance of materials and residual debris, etc., and meets the requirements of food industry safety and health standards. The mechanical components are made of SUS304 material. The overall structure is stable, safe and has a long service life. The surface of the material is sanded or polished, and the surface is bright and hygienic



Technical Data

Belt material	Food grade plastic modular belt
Belt width	600mm
Infeed height	800mm
Outfeed height	3270mm
Belt length	207m(180m effective)
Layer quantity	15
Outder dimension	5700*3900*3600mm





Detailed Images







Chain Type









 Application







Our Service

1,Project engineer is avaliable to abroad business to do field measurement.

2,We have our own professional engineer to provide detailed drawing for customer needed.

3,Will send engineers to overseas installation.
