Ручная цепная таль | Грузоподъемность 550 фунтов 1 падение 1/4 - 20 Метрическая грузоподъемность 3 тонны блокировка
- Категория: Material Handling Equipment >>>
- Поставщик: Guangdong,Gongyou,Lift,Slings,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 12.75 $* | 13.4 $* |
| Aug-15-2025 | 12.91 $* | 13.20 $* |
| Jul-15-2025 | 10.18 $* | 11.68 $* |
| Jun-15-2025 | 12.51 $* | 13.51 $* |
| May-15-2025 | 10.14 $* | 11.66 $* |
| Apr-15-2025 | 11.28 $* | 12.72 $* |
| Mar-15-2025 | 11.89 $* | 12.22 $* |
| Feb-15-2025 | 11.27 $* | 12.96 $* |
| Jan-15-2025 | 11.61 $* | 12.68 $* |
Характеристики
Products Description
Model | HSZ-0.5 | HSZ-1.5 | HSZ-2 | HSZ-3 | HSZ-5 | HSZ-10 | HSZ-15 | HSZ-20 | HSZ-30 | ||||||||
Capacity load (kg) | 500 | 1500 | 2000 | 3000 | 5000 | 10000 | 15000 | 20000 | 30000 | ||||||||
Lifting height (m) | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3 | 3 | 3 | ||||||||
Number of falls | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | ||||||||
Load chain diameter * pitch | 5*15 | 8*24 | 6*18 | 8*24 | 10*30 | 10*30 | 10*30 | 10*30 | 10*30 | ||||||||
Force (n) | 265 | 400 | 375 | 415 | 435 | 450 | 475 | 480 | 490 | ||||||||
Net weigh (kg) | 8.6 | 17.5 | 20 | 35 | 40 | 75 | 117 | 164 | 400 | ||||||||
Dimensions (mm) | |||||||||||||||||
A | 122 | 146 | 192 | 205 | 282 | 358 | 415 | 280 | 705 | ||||||||
B | 110 | 130 | 170 | 185 | 170 | 168 | 208 | 200 | 485 | ||||||||
K | 24 | 28 | 36 | 39 | 45 | 65 | 85 | 82 | 85 | ||||||||
D | 35 | 40 | 50 | 65 | 85 | 100 | 100 | 106 | 106 | ||||||||
Him | 315 | 355 | 470 | 555 | 720 | 820 | 920 | 1040 | 1390 | ||||||||
Related Product
CHAIN HOST-HSZ
HSZ chain hoist is widly used in machine installation, products lifting,agriculture, construction.
CHAIN BLOCK-CK/HSC
Superior Grade 100 load chain- wafios link, Din standard. double pawls supporting fail-safe brake mechanism.
CHAIN HOIST- VE360
This is designed for heavy industrial application.
CHAIN HOIS: VC-A
Double pawls supporting fail-safe brake mechaism.
CHAIN HOIS: VC-B
One of the best selling hoist. Capacity ranges from 500kg to30000kg.
CHAIN HOIS: VC-C
Automatic double pawls braking system. Brand light weight robust construction.
CHAIN HOIS: VC-D
Robust all steel construction. 0.5T-10T capacity. Brand heavy duty and compact design to meet all pertinent would standard.
LEVER HOIST: HSH(MINI)
Easy grip handle; completely sealed brake section; sealed body; easy to attach hook; one-touch adjustment.
LEVER HOIST: VL
One touch operation free chain adjustment. Grade 80 alloy load chain ISO and JIS standard.
LEVER HOIST: VA
Superior Gra 100 load chain- WAFIOS link, Din standard. Forged and heat treated load hooks with batch traceablity and stretch indictors..
LEVER HOIST: JHSS
Adjustable handle; Backward lever and forward lever; Spare shearpins; Buit-in shearing pin; Anchor bolt; high strength cast aluminium alloy body; Galvanized steel wire rope mounted on a reel.
ELECTRIC HOIST: HHBB
Light aluminum alloy shell; Inverse phase sequence protecting device; Limit switch; 24/36V device; side magnetic braking device; Side magnetic braking device;
ELECTRIC HOIST: PA
Unloading for various occasions hanging a small pieces of cargo. The protection class is IP54, and has thermal protection device.
ELECTRIC HOIST: CD1/ MD1
Independent reducer, its easy to load and unload. It has device with up and down stroke protection of break off limiter and can cut off main circuit in an emergency.
ELECTRIC HOIST: HHXG
Compact and high efficient motor; Most tensile safety hooks; compact and beauty chain container; Limit switch devices; Phase error relay.
Factory & Exhibition
Certification
FAQ
Q1: Where is your factory located? | Our factory is in Hebei, we havelogistics and warehousing center in Foshan Guangdong. | ||||||
Q2: How many products can you produce every day? | We can produce 2000 pieces everyday. | ||||||
Q3: Can you provide sample? | Yes, we can provide you sample, but you need to pay for the sample and freight firstly.We will return the fee after you place the order. | ||||||
Q4: Can you use our brand? | Yes, OEM is available. | ||||||
