Wellco W-SFS термоусадочная ткань рукава термоусадочные
Wellco W-SFS термоусадочная ткань рукава термоусадочные
Wellco W-SFS термоусадочная ткань рукава термоусадочные
Wellco W-SFS термоусадочная ткань рукава термоусадочные
Wellco W-SFS термоусадочная ткань рукава термоусадочные
Wellco W-SFS термоусадочная ткань рукава термоусадочные
Wellco W-SFS термоусадочная ткань рукава термоусадочные

Wellco W-SFS термоусадочная ткань рукава термоусадочные


Поделиться:


Цена:0,48 $ - 0,50 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-19-2025 0.90 $* 0.67 $*
Aug-19-2025 0.56 $* 0.22 $*
Jul-19-2025 0.73 $* 0.25 $*
Jun-19-2025 0.68 $* 0.75 $*
May-19-2025 0.7 $* 0.64 $*
Apr-19-2025 0.25 $* 0.44 $*
Mar-19-2025 0.83 $* 0.46 $*
Feb-19-2025 0.61 $* 0.15 $*
Jan-19-2025 0.54 $* 0.47 $*

Характеристики



Product Description


Operating temperature range (3000 hours): -40°C to 125°C
Minimum recovery temperature: 100°C (recommended recovery temperature 110°C to 130°C)
Maximum storage temperature: 60°C
Recovered after heating
2:1 shrink ratio
Fully recoverable fabric wall thickness: Approximately 1 mm .
Longitudinal change on full recovery is –10% to –20%.


Property
Test condition(s)
Performance*
Abrasion resistance
200g load, 0.3mm radius metal blade,
10Hz, 10mm stroke, 144 000 cycles)
23℃
No wear to underlying rubber hose
80℃
No wear to underlying rubber hose
125℃
No wear to underlying rubber hose
Thermal ageing
3000 hrs at 125°C
No deterioration in abrasion resistance at80°C
Low temperature flexibility
4 hours at -40°C, 10X diameter mandrel
No cracking
Cold impact
200g weight from 100mm at -40°C
No cracking
Thermal shock
100 cycles between -40°C and 125°C
No deterioration in abrasion resistance at 80°C
Fluid resistance
Antifreeze (50% ethylene glycol) Engine oil (SAE 10w/30) Mineral hydraulic fluid
Detergent (1% Teepol) Brake fluid (DOT 4) Unleaded gasoline Diesel fuel
Battery acid (1.25 SG H2SO4)
24 hr immersion at 23°C
No deterioration in abrasion resistance at 80°C


Size
Flat Width（mm)
ID as suplied（mm）
After shrinked（mm）
Φ6.0/3.0
12±2
≧6.0
≤3.0
Φ8.0/4.0
16±2
≧8.0
≤4.0
Φ10.0/5.0
20±2
≧10
≤5.0
Φ12.0/6.0
24±3
≧12
≤6.0
Φ14.0/7.0
27±3
≧14
≤7.0
Φ16.0/8.0
29±3
≧16
≤8.0
Φ20.0/10.0
36±3
≧20
≤10.0
Φ25.0/12.5
44±3
≧25
≤12.5
Φ30.0/15.0
53±4
≧30
≤15.0
Φ35.0/17.5
60±4
≧35
≤17.5
Φ40.0/20.0
68±4
≧40
≤20.0
Φ45.0/22.5
76±4
≧45
≤22.5
Φ50.0/25.0
85±5
≧50
≤25.0
Φ60.0/30.0
100±5
≧60
≤30.0
Φ65.0/32.5
107±5
≧65
≤32.5
Φ70.0/35.0
116±5
≧70
≤35.0
Φ80.0/40.0
132±5
≧80
≤40.0
Φ90.0/45.0
145±5
≧90
≤45.0
Other sizes are available upon request.






Packing & Delivery




To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.


Company Profile


Material Mixing
Extrude
.
Cross linking


Expand
Whole Production line
Test LAB




Shanghai Wellco International Limited is a professional Team with 18years experience for R & D, production, sales of special heat shrink Tube and other radiation crosslinking materials manufacturers. We concentrate on to providing all kinds of products and solution for Insulation,Connection ,Waterproof, high temperature ,Chemical resistant ,EMI and mechanical protection for the wire and cable .we has strong technical force with 20 years experience and advanced production equipment. We can supply (such as modifiedPE, PVDF ,FEP ,EPDM,Silicone,FKM.FEP.PTFE Etc materials)heat shrink tube and insulation tube. The products are widely used in the fields ofelectronic communication, automobile, high-speed rail, electotor, aviation, medical and other fields, such as insulation,
water-proof, electrostatic shielding, oil-resistant, chemical and high-temperature resistant Protection, etc. Our products have passed UL certification ,RoHS ,REACH.
We also can produce customized products or develop products with special requirements according to customer requirements, and we carry out our production according to ISO9001 and IATF16949 quality management system standards to ensure the stability and reliability of product quality.


FAQ


1. who are we?
We are based in Shanghai, China, start from 2017,sell to North America(20.00%),South Asia(20.00%),Southeast Asia(15.00%),Western Europe(15.00%),South America(5.00%),Eastern Europe(5.00%),Mid East(5.00%),Northern Europe(5.00%),Eastern Asia(3.00%),Domestic Market(3.00%),Southern Europe(2.00%),Africa(00.00%),Central America(00.00%). There are total about 5-10 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Heat Shrink Tube/Heat Shrink Mould Part/Marking Sleeve/Cold Shrink Tube

4. why should you buy from us not from other suppliers?
Shanghai Wellco International Limited is a professional R & D, production, sales of special heat shrink Tube and other radiation crosslinking insulation materials manufacturers And the founder have the experience for the insulation more than 20years

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union;
Language Spoken:English,Chinese
