EPS equipment shelter/PU shelter

telecom BTS shelter

polycarbonate shelter

mobile shelter





The shelter consist of :



Hybrid Power working system;



shelter frame , outer Iron clad ,inner PU, PVC static-free floor ,Security emergency door . Inside provide with :

AC distribution system ,lighting system , Fire and Security Safes system . 2°degree leaning roof with perfect draining system .Two air-conditions(12000BTU) In additional with shockproof ,windproof ,damp proof, waterproof , lightening protection , heat insulation , Fire and Security Safes system .etc.







Parameter

1	High Temperature Resistant	-60  +80
2	Anti-wind capability	55m/s
3	Anti-sun photochemical effect	Seal Rubber life time : 30 Years 30
4	shock resistance	8 Grade 8
5	salt spray test	4,, salt spray test 4 days , paint slightly rust allow , no rust on zinc coat .
6	Outside shelter steel thick	4mm
7	inner interlayer thick	0.5mm
8	Inner core materials heat transfer coefficient	0.027W/m.k
9	Inner core materials compression strength	100KPa
10	adherence force	0.09MPa
11	Shear stiffness	0.1MPa
12	Inner core materials Transverse rupture strength	500N/m2,1/250
13	Inner core materials fire resistance	B2
14	water absorptivity	4%
15	Roof load	3KN/m2
16	antistatic floor load	600KG/m2
17	IP	IP55
18	fire resistance	GB8624-1997B2 According to B2 of GB 8624-1997 << Building Materials burning performance Hierarchical Methodology >>
19	Water-proof	0.2Mpa,10mm/min,30min, Endure water pressure 0.2Mpa; Water spray intensity :10mm/min .( for 30 min)   No leakage inside
20	relative humidity	5%99%
21	Paint	anti-corrosive paint( For container only)
22	Load on floor	8KN/ m2





















We are an ISO9001:2000 certified manufacturer and exporter, and our products are widely used in Telecom, Netcom, mobiles, underground projects, highways, airports and railways. China Telecom, China Mobile, China Unicom and other top companies are our customers. Our products are widely exported to dozens of countries and regions, such as Russia, India, France, the USA, Australia, Malaysia and Singapore, and are used by SingTel, Turk Telecom, BSNL India, Viettel, Etisalat, Telestra, Mobily-Saudi Telecom, etc.

Depending on standard science management, strict quality control and perfect technical service, we will continuously offer state-of-the-art & cost-effective products and solutions to our esteemed customers globally.
