Обычная форма натуральная слюдяная пластина неправильной
Обычная форма натуральная слюдяная пластина неправильной
Обычная форма натуральная слюдяная пластина неправильной
Обычная форма натуральная слюдяная пластина неправильной
Обычная форма натуральная слюдяная пластина неправильной
Обычная форма натуральная слюдяная пластина неправильной
Обычная форма натуральная слюдяная пластина неправильной

Обычная форма натуральная слюдяная пластина неправильной


Поделиться:


Цена:13 184,14 ₽*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-16-2025 15689.12 $* 16473.65 $*
Aug-16-2025 15557.6 $* 16335.11 $*
Jul-16-2025 13052.54 $* 13705.22 $*
Jun-16-2025 15293.66 $* 16058.57 $*
May-16-2025 13316.56 $* 13982.15 $*
Apr-16-2025 15030.64 $* 15782.52 $*
Mar-16-2025 14898.55 $* 15643.47 $*
Feb-16-2025 14766.28 $* 15504.74 $*
Jan-16-2025 14634.40 $* 15366.73 $*

Характеристики

---->>>Click it or Chat now for FREE SAMPLES
Specification
Items
Phlogopite Mica plate
Muscovite Mica plate
Content of mica
90%
90%
Content of adhesive
10%
10%
Density
2.35g/cm3
2.35g/cm3
Rating of Temperature (continued)
700°C
600°C
Rating of Temperature (intermittent)
1000 °C
900 °C
Water Absorption
<2
<1
Electrical Strength at 20°C
>15 KV/mm
>15 KV/mm
Dielectric Resistance at 23°C
1017Ω·cm
1017Ω·cm
Dielectric Resistance at 500°C
1012Ω·cm
1012Ω·cm
--->>>Click for customized OEM & ODM requirement
* Thick Mica plate for high-performance thermal and electrical insulation * Thick Mica plate for high-performance thermal and electrical insulation is designed for electromechanical and thermomechanical applications requiring , It is used as a replacement for asbestos and other insulating boards for a variety of applications.
◆ Excellent insulating properties at high temperature: At 500-1000℃ operating ambient temperature, the voltage breakdown resistance is 15KV/mm; ◆ Good tensile property: It can be processed into a variety of shapes without layer separation; ◆ Excellent environmental protection performance: The product contains no asbestos, and has less smoke and odors, even smokeless and odorless when heating; ◆ Excellent acid and alkali resistance, and oil resistance. Availability for mica plate Thickness: 0.1mm 0.15mm 0.2mm~100mm Length×Width: 1000×600mm 1000×1200mm 1000×2400mm Note: The product less than 2.0mm thickness can be formed by stamping. The products larger than 2.0mm shall be processed by turning, milling, drilling and other processes.
Application
Rigid Mica Sheet has a wide range of following applications: To implement resistor support, expecially for heating elements in toasters, hair dryers; To manufacture closed heating elements such as heater bands, heating elements, clothes irons and presses,kettles, cooking appliances, heating elements for extrusion machines; To used as thermal insulation in circuit breakers such as divider between components affected by a high heat loads.
Packing & Delivery
Company Profile
Foshan Kuliwei Industrial Material Co., Ltd., is located in Foshan China, with plant area of over 2000㎡.Our factory has advanced production equipment 20 sets and technology, and strict implementation of international quality management system standards.We are specializing in below productions more than 13+ years factory OEM/ODM experience：   1. Electrical insulation materials：Mica sheet、transparent natural mica sheet; 2. Packing foam productions ：EPDM、EVA、RB、PORON、CR、SBR、SPONGE 、EPE foam sheet、foam strip、foam pipe、foam pad、foam inserts; 3. Tape：foam tape、double side adhesive tapes、reflective tape 、 anti slip adhesive tapes、conductive tape; 4. Adhesive pad（Silicone rubber、Foam、Felt wood）; 5. Conductive productions（thermal conductive silicone 、conductive foam）; 6. PC overlay 、acrylic sheet 、PVC PET PP;   In order to better serve customers, we have established 6 guarantee systems, such as mature supply system, warehousing system, packaging system, QC system, pre-shipment inspection system and after sales service system.   Professional working team,high efficiency reaction and professional experience assure that you will enjoy the excellent service from us.   Foshan City Kuliwei technical Co., Ltd. Email：aigaofactory@126.com Phone/Wechat：+86 13380282225
FAQ
1.Are you a factory or a trading company?
A1:Yes,we are a professional manufacture of the thermal materials factory over 18 years.
2.Could you offer free samples?
A2:Yes,we could offer samples for free,but if you want to printing your logo and need very big large size,maybe need to charge a little samples fee,the samples fee will be return as part of deposit after your enough orders.
3.Could we visit your factory?
A3:Yes,Kuliwei very welcome all customers and friends to our factory,we could have some tea.
