Конструкция стальной птицефермы для курицы
US $30.00-$60.00
Легкое металлическое здание сборная промышленная стальная конструкция Складская Высококачественная Легкая
- Категория: >>>
- Поставщик: Xinji,Shuangyi,Color,Steel,Factory
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.56 $* | 0.78 $* |
| Aug-16-2025 | 0.14 $* | 0.9 $* |
| Jul-16-2025 | 0.20 $* | 0.23 $* |
| Jun-16-2025 | 0.38 $* | 0.25 $* |
| May-16-2025 | 0.85 $* | 0.31 $* |
| Apr-16-2025 | 0.87 $* | 0.26 $* |
| Mar-16-2025 | 0.31 $* | 0.92 $* |
| Feb-16-2025 | 0.44 $* | 0.52 $* |
| Jan-16-2025 | 0.52 $* | 0.75 $* |
Характеристики
Main Steel Frame | Frame column and beam | Q355 |
End-wall column | Q355 | |
process 1 | Welding | Automatic submerged arc welding |
process 2 | Rust removal | Sand blasting |
process 3 | Surface finish | Alkyd paint or galvanized |
process 4 | Intensive bolt | M20-M30,Grade 10.9S |
Supporting Sys | Angle bracing | Angle iron L50x4 |
Roof bracing | Φ20, Round Steel | |
X bracing between columns | Φ20, Round Steel | |
Tie rod | Φ10, Round Steel | |
Roof bar | 32 mm diameter Steel Pipe | |
Purlin | C/Z100-250, Q235, galvanized | |
Roof Sys | Roofing material | 0.5mm steel plate,Service life 20 years |
Skylight panel | 1.5mm V840/V760 | |
Gutter | Galvanized sheet or Stainless steel | |
PVC downspout | 160 | |
Wall Sys | Wall material | 0.5mm steel plate,Service life 20 years |
Door | Electric rolling door | |
Window | Aluminum alloy or plastic steel window | |
Others | Crown 3-50T | Can be customized |
Steel platform | Can be customized | |
Parapet (wall) | Can be customized |
We need to know something like this：
1.Where the building is located?
1.Where the building is located?
2.What is the build length/width/heigth?
3.Whether the building needs thermal insulation?
4.How many doors and windows?
We will use software to calculate the stability of the building frame system under live load, constant load, wind, snow, earthquake conditions and provide some good advice to you
At the same time, there will be a 3D renderings for you to confirm
Complete design drawings can guide each step of construction
In the quotation, the use of each material is clear at a glance, even if it is 1 nail
Step 5, Production
Mechanical precision control error within 1mm
Can produce 100000 Sqm /month
Step 6,Loading transport
According to the volume and weight of the goods, we choose different containers for you to save transportation costs
Step 7,On-site installation
We offer online technical guidance, or a paid dispatch
