Звуковой воздуходувка для выдувания соли в котельной системе сделано

Звуковой воздуходувка для выдувания соли в котельной системе сделано

Категория: Boiler & Parts >>>
Поставщик: Nanjing,Bang,Win,Imp,&,Exp,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.45 $*	0.11 $*
Aug-16-2025	0.36 $*	0.11 $*
Jul-16-2025	0.56 $*	0.32 $*
Jun-16-2025	0.63 $*	0.0 $*
May-16-2025	0.84 $*	0.61 $*
Apr-16-2025	0.68 $*	0.95 $*
Mar-16-2025	0.39 $*	0.23 $*
Feb-16-2025	0.97 $*	0.21 $*
Jan-16-2025	0.86 $*	0.57 $*

Характеристики

Product Advantages

Sonic soot blower operating principle

The intense and rapidly changing vibration of sound waves will separate the adhesion state of ash fouling on the heating surface and cause scaling fatigue fracture and breakage.Ash and scale are removed from the heating surface and carried out of the flue under the action of sound waves.

Sonic soot blower specification
Acoustic frequency	32.5~250Hz
Radiated acoustic power	≥600W
Sound pressure level	130~150db
Radiative directivity	Spherical shape
Dynamic medium	Compressed gas
Motor power	380V 50Hz 0.55~1.1KW
Dynamic medium parameter	Pressure:0.3~0.6 mpa; Flow:0.8~1.4 m³/min
Operation	manual and continuous
Main body material	Superalloy and heat-resistant stainless steel ; Heat resisting: 950 degrees Celsius
Piping interface	Jb81-59 PN1.6,DN25 plain welded steel flange or 32 Seamless steel tube welding

Different type for your reference
Type	Model	Technical parameters	Apply & Advantages
Whistle frequency frequency horn sonic soot blower	BWSB1	Frequency:30~1950Hz Pressure:≥130db Power:≥1900W	Used for cleaning small boilers
Maintenance-free resonant sonic soot blower	BWSB2	Frequency:30~1950Hz Pressure:130~145db Power:≥2150W	Used for cleaning small and medium sized boilers. Features: new energy saving, no maintenance, high temperature resistance and easy installation
Maintenance-free resonator high-power trumpet type sonic soot blower	BWSB3	Frequency:30~2100Hz Pressure:≥150 db Power:≥3150W	Used for cleaning large and medium-sized petrochemical power boilers. Features new energy saving, no maintenance, high temperature resistance and easy installation
Low frequency sonic soot blower	BWSB4	Frequency:30~2100Hz Pressure:≥150 db Power:≥2950W	Used for cleaning large and medium-sized petrochemical power boilers. Features new energy saving, no maintenance, high temperature resistance.

Accessories list
Item	Qty	Remark
Sonic soot blower	6 sets	Seller provide
PLC	1 set	Seller provide
Solenoid valve	6 pcs	Seller provide
Filter	6 pcs	Seller provide
Hand-operated valves	6 pcs	Seller provide
Butt-joint	30 pcs	Seller provide
Hickey	5 pcs	Seller provide
Union	6 pcs	Seller provide
Flange	6 pcs	Seller provide
Set bolt	72 sets	Buyer provide
Embedded casing	6 pcs	Buyer provide
Cable	according to apply	Buyer provide

Compare with other soot blower

	Steam soot blower	Shock wave soot blower	Sonic soot blower
Operating principle	The jet impinging kinetic energy of high pressure steam is used to remove ash and coking	The combustible gas is mixed with air to produce shock wave blowing ash after ignition and explosion	Using the vibration and disturbance of sound wave energy to blow ash
Sound pressure	80~100db	160~170db	130~150db
Blowing effect	Good, to clear ash, coking is effective, to ash dead Angle is invalid.	Very good.It has good effect on removing accumulated ash and coking.But easily damage the tube wall.	Very good .The removal of the original ash has a certain role in preventing the deposition of ash, but the first removal of ash, coking is ineffective.Need to clear ash and coking first.
Structure	Very omplex, the mechanical structure part is very complex	Complex, the gas tank must be frequently replaced, the control part of the air, gas flow detection, high-energy ignition control, gas leakage control	Simple, single solenoid valve, acoustic sub - chip
Reliability	Lowest, mechanical failure rate, drive motor is easy to burn, stable operation period is short	Low, igniter, mixed gas tank has high temperature ablation, corrosion, a long - term risk of intensity reduction vessel blasting. Ignition instability, shock wave strength is strong and weak is not easy to control	High,vulnerable parts, diaphragm, rotary valve, etc
Energy consumption	High ,each blow must consume the 0.7% steam produced by the boiler	Low, pulse operation, low gas and gas consumption	Lowest, miscellaneous air consumption
Safety performance	Low, boiler tube tube wall corrosion, product tube burst accident	Lowest , danger of explosion in boiler or return explosive	High, pure air as the medium for safe and clean
Apply	Convection tube bundle heating surface	All the heating surfaces	All the heating surfaces
