355 мм тяжелый подшипник воздуходувки противоизносостойкий вентилятор Охлаждающий

Описание и отзывы

Трекер стоимости

Характеристики



 Advantages



· The Fan with Compact structure.
· The impeller will do by dynamic balancing tests. It greatly improves the stability of the impeller operation, and reduces the vibration and noise.
· The Fan with advantages of small volume, light weight, angle adjustable and convenient for installation and maintenance.
· Transportation gas temperature at -20℃ ~ 300℃.
· The fan performance be test by airway or AMCA both available, the fan performance data is truth and reliable.
· Fan Material is optional according to your need.
· Customzation is acceptable.



Backward Centrifugal Fan - SWSI - BSW
Model	Speed	Air flow	Total Pressure	Power
	rpm	m³/h	Pa	kw
BSW280	2900	1177-3709	1133-317	1.5
BSW315	2900	1734-5463	1611-451	2.2
	2200	1271-4006	825-231	1.1
	1450	838-2640	376-105	1.1
BSW355	2900	2399-7559	1821-509	3
	2400	1985-6256	1247-349	2.2
	1900	1572-4952	782-219	1.1
	1450	1199-3779	455-127	1.1
BSW400	2900	3432-10813	2312-647	5.5
	2400	2840-8949	1583-443	4
	1900	2248-7084	992-278	2.2
	1450	1716-5407	578-162	1.1
BSW450	2900	4886-15396	2870-818	7.5
	2400	4044-12742	1966-561	5.5
	1900	3201-10087	1232-351	3
	1450	2443-7698	718-205	1.1
BSW500	2900	6702-21119	3721-1061	15
	2400	5547-17478	2548-727	11
	1900	4391-13837	1597-455	5.5
	1450	3351-10560	930-265	2.2
BSW560	2240	7273-22918	2785-794	15
	1450	4708-14836	1167-333	3
	1250	4059-12789	867-247	2.2
	960	3117-9822	511-146	1.5
BSW630	2240	10356-32632	3524-1005	18.5
	2000	9247-29136	2810-801	15
	1800	8322-26222	2276-649	11
	1600	7397-23309	1712-488	7.5
	1400	6704-21123	1477-421	7.5
	1250	5779-18210	1097-313	3
	1120	5178-16316	881-251	2.2
	960	4438-13985	647-185	1.5
BSW710	1950	12904-40661	3392-967	22
	1800	11912-37534	3028-863	18.5
	1600	10588-33363	2393-682	11
	1440	9596-30235	1929-550	7.5
	1250	8272-26065	1394-397	7.5
	1120	7412-23354	1119-319	5.5
	1000	6618-20852	892-254	4
	960	6353-20018	783-223	3
BSW800	1800	17040-53693	3495-996	30
	1600	15147-47727	2899-827	22
	1440	13632-42954	2349-670	18.5
	1250	11833-37287	1753-500	11
	1120	10603-33409	1353-386	7.5
	960	9088-28636	1044-298	7.5
	800	7573-23863	718-205	3
	710	6721-9626	571-554	2.2
		11551-21179	545-163	3
Click here to view more models.







 Applications



· For building ventilation system, air-conditioning(HVAC), purification equipment and High-temperture system.
· For equipments or system of filtration & drying, fume hood & spray booth, paiting room, food processing , kitchen room and so on.



CHOSEN VENT TECH LTD. is a manufacturer of ventilation and cooling equipment with more than 10 years experience.



Professional Products:

1. Centrifugal Fan, Axial Fan, HVLS Fan, Fan Impeller, Mist Fan.

2. Non-standard units & small order.

3. Accessories: Forward Impeller, Backward Impeller, Axial Impeller, Atomizer.

4. Meanwhile we specialized in ventilation & cooling solution of industrial building.



Professional Manufacturing:

1. Experienced engineers and R&D team to support the product technology & development.

2. Advanced manufacturing & inspection equipment, we have Laser cutting equipment, CNC equipment, Dynamic balance equipment, Air-flow/pressure/speed testing equipment.

3. Inspection. All products with serious inspection in hundred percent before delivery.



Professional Service:

1. Our products be export to more than 30 countries.

2. On time delivery.

3. The experienced customers service team provides excellent communication for all customers to answer questions and solve problem.



Our Aim:

1.Company's Aim: Honesty, Gratitude.

2.Service's Aim: Professionalism, Scrupulous, Responsibility.

3.Product's Aim: High quality, Reasonable price, for customers' requirements.



Our mission:

1. Provide quality products all over the world.

2. Set up fine managing and brand credit for "MADE IN CHINA"
