Description:

Features:

4 digits display current pressure

Fast swith speed,320 times/s

Span zoom and shift

Preset swith value and delay swith output

Optional switch output function

Luminous diode for switch action

Button adjustment and set up parameters on site

2 lines switch output,load capacity 1.2A

 4-20Ma output

330°rotary display window

Dimensions and connections:





Electrical:  H One Analog(Hirschmann)

Connection: M Two-way switch+one Analog(M12-5P)

Thread connection:G12               G1/2

                                       G14               G1/4

                                  M20               M20*1.5

Swith type:                P                    PNP

                                  N                    NPN

Control range:         According to customer's request.

 SPECIFICATION

Control range	-0.1~0…100mPa	Control accuracy	<0.5%F.S
Stability	≤0.1%/year	Display accuracy t	±0.1%/ F.S/℃
Display	4 digits Nixie Tube	Display range	-1999~9999
Power range	24VDC±20%	Swith type	PNP/NPN
Load capacity	<24v/1.2A	Swith Life	>1million Times
Response time	<5ms	Protection Grade	IP65
Operating Temperature	-30~80℃	Medium Temperature	-40~150℃

Remark:Heat radiator must be used if medium temperature over 80℃

Apllication:

It is widely used in hydraulic field.
