Устройство для сбора проволочной катушки устройство захвата
- Категория: Металлические приемные механизмы >>>
- Поставщик: Shijiazhuang,Satle,Machinery,Manufacture,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.47 $* | 0.55 $* |
| Aug-18-2025 | 0.98 $* | 0.56 $* |
| Jul-18-2025 | 0.54 $* | 0.91 $* |
| Jun-18-2025 | 0.66 $* | 0.62 $* |
| May-18-2025 | 0.26 $* | 0.63 $* |
| Apr-18-2025 | 0.54 $* | 0.49 $* |
| Mar-18-2025 | 0.92 $* | 0.80 $* |
| Feb-18-2025 | 0.51 $* | 0.4 $* |
| Jan-18-2025 | 0.81 $* | 0.23 $* |
Характеристики
Product Description
Specification
Name | take-up spooler fishing line wire drawing machine |
Item No | ST560 |
Bobbin size | 560 |
Raw material | Stainless steel wires |
Speed | Match with wire drawing machine |
Motor Power | 30kw |
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
The packing will be plastic film or according customer's demand.
Company Profile
SATLE MACHINERY established in 2001.We are the professional manufacturer have more than 20 years of experience in making all kinds of wire and cable machinery,realize the wire from drawing to extruding. we are the factory not the trade company,Machine's body and other key components and parts are produced by our own factory, quality is reliable.,and we can control .the price;.the quality and .the delivery time; We make the whole set of welding wire production line and whole set metal wire drawign machine,layer winding machine,straightening cutting machine and cable auxiliary equipment(for example:wire winding machine,take up and pay-off machine,wire wrapping machine and so on.
Detailed Images
Machine Parts
Name: Capstan/drum
Brand: SATLE
Original:China
Steel ZG45~55, hardness alloy tungsten carbide is spraying-painted on working surface, with HRC60, lifetime>=26000hours. The height of the capstan is 280mm. The height of spraying tungsten carbide is 80mm and the thickness is 2mm. The temperature of the capstan< 80℃. Roughness <0.8μmm. There are operation buttons in front of each capstan used to adjust the tension. Cooling type: narrow slit water cooling with water proof and anticorrosive treatment. Water volume ：6m3/h ,Water pressure ≥0.25MPa, Air volume：1.5m3/h ,Air pressure ≥0.6MPa.
Main Features
Name: Die box
Brand: SATLE
Original: China
Welding part is adopted for die box, the spraying-painted tungsten carbide is adopted for the surface of guide wheel and guide roller. The die box is divided into lub. powder cavity and water cooling cavity (water flowing automatically for cooling)
Machine Parts
Name: Control system
Brand: Siemens
Original: Germany
PLC:Siemens/INVT
Inverter:INVT/Sinee
Low voltage appliance:Chint
Main Features
Name: Motor
Brand: Hebei/Siemens
Original: Germany
22kw,Inverted motor.There is a brake to stop the motor and avoid turning in the opposite direction.Brake material: Nodular cast iron.
FAQ
1.How about our quality ?
We continuously develop and improve our products and are widely used in many fields such as industrial, technical, medical and aerospace. Quality is at the world's leading level
2.How about the price ?
Very low price, don’t worry about it, All fees you pay will be used on your machine. The price depends on your expectations of the machine.
3.How about our service?
Once we get your inquiry for our products, we will make offer within one hour ,and for reply you any doubt at any time
4.How about the brand of electric parts of machine?
We use famous brand as following
Siemens / HD motor
Siemens /ABB / Inovance inverter
Siemens/ Inovance touch screen
Schneider low voltage electric. etc.
5.How about packaging?
1.Plastic wrap with dryer agent
2.Plywood box with plastic wrap and dryer agent
3.Carton with plastic wrap and dryer agent
4.SEA , TRAIN , AIR according to clients requirement
6.How about the delivery?
We promise that we provide wire machine, mold, brushed powder machine test operation service in the workshop, and then ship, you carefully check and then ship
7.How about delivery time?
It is 30 days. According to your specific requirements for the machine.
8.How about the after service?
When the machine has a problem, the Engineers available to service machinery overseas.
9.How to prove what you said?
If you are convenient, you can visit our factory at any time, and when you visit us, you will see the running machine in our factory.
10.Where is our factory?
Shijiazhuang city China
Our company is only 30 minutes away from ZHENGDING International Airport in Hebei Province, we can pick you up when you come to this airport
11.How about the invitation letter?
We will do that according to your request , and give you invitation letter in one week.
12.Please provide following information if you want to directly quotation:
1. Wire Material:
2. Inlet Wire Diameter range:
3. Outlet wire Diameter range:
4. Where and what does the wire use for
We continuously develop and improve our products and are widely used in many fields such as industrial, technical, medical and aerospace. Quality is at the world's leading level
2.How about the price ?
Very low price, don’t worry about it, All fees you pay will be used on your machine. The price depends on your expectations of the machine.
3.How about our service?
Once we get your inquiry for our products, we will make offer within one hour ,and for reply you any doubt at any time
4.How about the brand of electric parts of machine?
We use famous brand as following
Siemens / HD motor
Siemens /ABB / Inovance inverter
Siemens/ Inovance touch screen
Schneider low voltage electric. etc.
5.How about packaging?
1.Plastic wrap with dryer agent
2.Plywood box with plastic wrap and dryer agent
3.Carton with plastic wrap and dryer agent
4.SEA , TRAIN , AIR according to clients requirement
6.How about the delivery?
We promise that we provide wire machine, mold, brushed powder machine test operation service in the workshop, and then ship, you carefully check and then ship
7.How about delivery time?
It is 30 days. According to your specific requirements for the machine.
8.How about the after service?
When the machine has a problem, the Engineers available to service machinery overseas.
9.How to prove what you said?
If you are convenient, you can visit our factory at any time, and when you visit us, you will see the running machine in our factory.
10.Where is our factory?
Shijiazhuang city China
Our company is only 30 minutes away from ZHENGDING International Airport in Hebei Province, we can pick you up when you come to this airport
11.How about the invitation letter?
We will do that according to your request , and give you invitation letter in one week.
12.Please provide following information if you want to directly quotation:
1. Wire Material:
2. Inlet Wire Diameter range:
3. Outlet wire Diameter range:
4. Where and what does the wire use for
Winnie Wang
We have great interest in developing business with you,should you have any inquiries or comments,we would be glad to talk in details .
