Химическая жидкость алкидный полимерный реактор резервуар Полная производственная
- Категория: Reactors >>>
- Поставщик: Nanjing,Bang,Win,Imp,&,Exp,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 2118.99 $* | 2224.75 $* |
| Aug-16-2025 | 2100.67 $* | 2205.8 $* |
| Jul-16-2025 | 1762.54 $* | 1850.32 $* |
| Jun-16-2025 | 2065.60 $* | 2168.76 $* |
| May-16-2025 | 1798.17 $* | 1888.37 $* |
| Apr-16-2025 | 2029.91 $* | 2130.53 $* |
| Mar-16-2025 | 2011.4 $* | 2112.96 $* |
| Feb-16-2025 | 1994.38 $* | 2094.33 $* |
| Jan-16-2025 | 1976.93 $* | 2075.67 $* |
Характеристики
Product Description
Reactor tank introduction
The general understanding of the reactor is that the container with physical or chemical reaction, through the structural design and parameter configuration of the container, the heating, evaporation, cooling and low-speed mixing functions required by the process are realized. We say that the reactor generally includes: agitator, emulsifying kettle, dispersing kettle, lacquer kettle, crystallization kettle, polymerization kettle and a series of kettle.
Common application:petroleum, chemical industry, rubber, pesticide, dye, medicine, food, used to complete the vulcanization, nitrification, hydrogenation, alkylation, polymerization,condensation and other process of pressure vessels, such as reactor, reaction pot, decomposition pot, polymerization kettle;
Normal Specification | ||||||||||
Model | Motor Power | Material | Tank structure | Inner cylinder common size | Conventional nozzle | |||||
100L | 0.55KW | 304/316L | Single/multi-layer | Ø500*h500*t3 | Feed port, discharge port, breathing port, spare port, cleaning port, liquid level meter port. General reactor refers to the kettle body with mechanical seal. Conventional quotation does not include pump, pipe, valve, instrument and other accessories. If you need to price at cost. | |||||
200L | 0.75KW | 304/316L | Single/multi-layer | Ø600*h600*t3 | ||||||
300L | 0.75KW | 304/316L | Single/multi-layer | Ø750*h600*t3 | ||||||
500L | 1.5KW | 304/316L | Single/multi-layer | Ø900*h750*t3 | ||||||
1000L | 2.2KW | 304/316L | Single/multi-layer | Ø1000*h1200*t3 | ||||||
2000L | 4.0KW | 304/316L | Single/multi-layer | Ø1250*h1500*t3 | ||||||
3000L | 5.5KW | 304/316L | Single/multi-layer | Ø1500*h1500*t3 | ||||||
5000L | 7.5KW | 304/316L | Single/multi-layer | Ø1800*h1800*t4 | ||||||
10000L | 11KW | 304/316L | Single/multi-layer | Ø2000*h3000*t4 | ||||||
How to customized your product? Pls inform us the specification as below: | |||||
Capacity | such as 400L,1600L etc.. | ||||
Placement structure | Vertical, hanging, etc | ||||
Material | SS304,SS316L,etc.. | ||||
Parameter of electric machine | including voltage frequency phase number (e.g. AC380V/50HZ/3PH), power (e.g .0.55 KW), rotational speed (e.g .36 RPM),explosion-proof (depending on whether the material has explosive components), frequency conversion motor (depending on whetherspeed regulation is required), etc | ||||
Agitator form | Blade type, frame type, scraper type, three-leaf propulsion type, screw belt type, etc. | ||||
Heat mode | jacket type, outer coil type (semi-circular coil), honeycomb plate type, inner coil type, etc | ||||
Size | For example, specify not more than height, or specify not more than diameter, or specify length and width, etc.. | ||||
Pressure | Normal pressure, positive pressure (such as 2 bar pressure), negative pressure (machine commonly known as vacuum, such as -0.095Mpa) and so on. Note that the reactor generally has a jacket, jacket and tank with two pressure values to be provided. | ||||
Pipe nozzle | Additional openings other than conventional ones, such as safety valve, pressure gauge, temperature, electronic level gauge, etc | ||||
Accessories | Valves, level gauges, air filter filters, thermometers, pressure gauges, discharge pumps, vacuum pumps, frequency converters, etc | ||||
If you don't know the requirements, you can provide your material name and characteristics, we calculate and design according to the experience of previous customers. | |||||
CONTACT US
Whatsapp/Mob: +86 18936889762; Email: gaoyuu@njbangwin.com
Production Equipment
Project Cases
Our Factory
Production Process
FAQ
1.Q:Are you trade or manufacturer?
A : We are a factory with an international sales company specialized in support for global distributors.
2.Q:How long is the service time?
A:It could use several year without external force factors.We have 1 year warranty.
3.Q:What is the payment terms?
A:We accept T/T and L/C,also can use alibaba trade assurance.
4.Q:How to choose the shipment way?
A:It is according to the order quantity,delivery time,costs and customs policy,etc.(Or decide by customers).
5.Q:How about the surface finishing?
A:Machine finished,matt and mirror polished,it will be confirmed by customer’s requirement.
A : We are a factory with an international sales company specialized in support for global distributors.
2.Q:How long is the service time?
A:It could use several year without external force factors.We have 1 year warranty.
3.Q:What is the payment terms?
A:We accept T/T and L/C,also can use alibaba trade assurance.
4.Q:How to choose the shipment way?
A:It is according to the order quantity,delivery time,costs and customs policy,etc.(Or decide by customers).
5.Q:How about the surface finishing?
A:Machine finished,matt and mirror polished,it will be confirmed by customer’s requirement.
