Защитный фильтр из нержавеющей стали картридж для фильтра
- Категория: Other Industrial Filtration Equipment >>>
- Поставщик: Fujian,Huamo,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 50.12 $* | 53.91 $* |
| Aug-15-2025 | 50.16 $* | 53.70 $* |
| Jul-15-2025 | 42.78 $* | 44.16 $* |
| Jun-15-2025 | 49.48 $* | 51.42 $* |
| May-15-2025 | 42.84 $* | 44.87 $* |
| Apr-15-2025 | 48.68 $* | 50.45 $* |
| Mar-15-2025 | 47.1 $* | 49.61 $* |
| Feb-15-2025 | 47.4 $* | 49.70 $* |
| Jan-15-2025 | 47.4 $* | 49.39 $* |
Характеристики
Product Description
Cartridge filter, also known as security filter. The shell is made of high quality stainless steel, filter using molded filter,
The liquid went through filter under pressure, residue left on the filter, and the filtrate outflow through the filter can
effectively remove impurities in the water, sediment and suspended solids, bacteria. Molded filters are: cloth, screen, filter,
sintered filter tube, wound filter, melt-blown filter, micro-porous filter and multi-function filter. Due to different filter, the
filter pore size is not the same. Precision filter is between the sand filter (coarse) and a filter between ultra-filtration,
filter pore size generally between 0.01-120um.For the same form of filter,it is divided into different models by their dimensions.
The liquid went through filter under pressure, residue left on the filter, and the filtrate outflow through the filter can
effectively remove impurities in the water, sediment and suspended solids, bacteria. Molded filters are: cloth, screen, filter,
sintered filter tube, wound filter, melt-blown filter, micro-porous filter and multi-function filter. Due to different filter, the
filter pore size is not the same. Precision filter is between the sand filter (coarse) and a filter between ultra-filtration,
filter pore size generally between 0.01-120um.For the same form of filter,it is divided into different models by their dimensions.
Specification
item | value |
Condition | New |
Applicable Industries | Hotels, Building Material Shops, Machinery Repair Shops, Food & Beverage Factory, Home Use, Retail, Food Shop, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company |
After Warranty Service | Online support |
Local Service Location | None |
Showroom Location | None |
Video outgoing-inspection | Provided |
Machinery Test Report | Not Available |
Marketing Type | Ordinary Product |
Warranty of core components | 1 Year |
Core Components | Pressure vessel |
Place of Origin | China |
Fujian | |
Brand Name | HUAMO |
Warranty | 1 Year |
After-sales Service Provided | Online support |
Product name | Stainless Steel Cartridge Filter |
Model | MG02 |
Application | Liquid Filtration |
Product Type | Filtration equipment |
Size | 20" |
Material | SS 304 / SS316 |
Package | 75*27*26cm/1 pc |
Function | Water purification |
Brand | HUAMO |
Maximum working pressure | 150 PSI |
Model | A(mm) | B (mm) | D(mm) | E(mm) | F(mm) | Inlet/outlet | Drain |
HM-MG2-W3L1 | 180 | 75 | Φ170 | Φ216 | 230 | 1"-1 1/2" | 1/4"-1/2" |
HM-MG2-W3L2 | 180 | 75 | Φ170 | Φ216 | 230 | 1"-1 1/2" | 1/4"-1/2" |
HM-MG2-W3L3 | 180 | 75 | Φ170 | Φ216 | 230 | 1"-2" | 1/4"-1/2" |
HM-MG2-W3L4 | 180 | 75 | Φ170 | Φ216 | 230 | 1"-2" | 1/4"-1/2" |
HM-MG2-W5L1 | 180 | 75 | Φ200 | Φ248 | 260 | 1"-1 1/2" | 1/4"-1/2" |
HM-MG2-W5L2 | 180 | 75 | Φ200 | Φ248 | 260 | 1"-1 1/2" | 1/4"-1/2" |
HM-MG2-W5L3 | 180 | 75 | Φ200 | Φ248 | 260 | 1"-2" | 1/4"-1/2" |
HM-MG2-W5L4 | 220 | 120 | Φ200 | Φ248 | 260 | 1"-2" | 1/4"-1/2" |
HM-MG2-W7L1 | 220 | 120 | Φ250 | Φ310 | 310 | 1 1/2"-2" | 1/2" |
HM-MG2-W7L2 | 220 | 120 | Φ250 | Φ310 | 310 | 1 1/2"-2" | 1/2" |
HM-MG2-W7L3 | 220 | 120 | Φ250 | Φ310 | 310 | 1 1/2"-2 1/2" | 1/2" |
HM-MG2-W7L4 | 220 | 120 | Φ250 | Φ310 | 310 | 1 1/2"-2 1/2" | 1/2" |
