Портативная лебедка б/у электрическая мини 230

Описание и отзывы

Трекер стоимости

Характеристики

Product Description

portable winch used mini 230v electric winch wire rope capstan winch

JM electric slow and large tonnage hoist, JM electric slow and large tonnage hoist, JK electric high speed hoist, JKL manual fast winding hoist, 2JKL manual double fast winding hoist, electric and manual dual-use hoist, JT speed regulation hoist, KDJ miniature hoist, etc., can only be used on the ground, can be modified for the ship.This product has high versatility, compact structure, small volume, light weight, heavy weight, easy to use and transfer, widely used in construction, water conservancy projects, forestry, mining, wharf and other material lifting or towing, but also can be used as a modern electronic automatic operation line supporting equipment.JM series are geared hoist.It is applicable to civil construction and installation works of construction and installation companies, mining areas and factories.


Specification



portable winch used mini 230v electric winch wire rope capstan winch



Detailed parameters of the winch
Tonnage	Model	Velocity m/min	Brake	Motor kw	Pull kn	Weight kg	rope capacity
0.5	JK triaxial	35-38	Electromagnetic	3	5	90	80-120
	JK triaxial	25-28	Electromagnetic	3	5	90	80-120
1.5	JK triaxial	25-28	Electromagnetic	7.5	15	220	100-200
	JK triaxial	35-38	Electromagnetic	7.5	15	220	100-200
	JK four axis	15-18	Electromagnetic	7.5	15	300	100-200
2	JK triaxial	25-28	Electromagnetic	11	20	270	100-200
	JK triaxial	35-38	Electromagnetic	11	20	270	100-200
	JK four axis	15-18	Electromagnetic	11	20	300	100-200
5	JK four axis	22-25	Hydraulic	18.5	50	900	150-300
	JK four axis	12-14	Hydraulic	18.5	50	900	150-300
8	JK speed regulating four axes	6-8	Hydraulic	YZR18.5-6	80	1700	200-400
10	JK speed regulating four axes	6-8	Hydraulic	YZR22-6	100	1900	200-400



A device that drives a reel or winding rope by human or mechanical power to perform traction.

Coaxial hoist :(also known as miniature hoist) motor and wire rope in the same drive shaft, light and small, save space (its tonnage includes 200 kg, 250 kg, 300 kg, 500 kg, 750 kg, 1000 kg, etc.).

1. Slow hoist: the hoist with the rated speed of steel wire rope on the drum being about 7~12m/min.

2. Quick hoist: the hoist with the rated speed of steel wire rope on the drum about 30m/min.

3. Electric winch: the winch which USES the motor as the power and rotates the drum through the driving device.

4. Speed regulation hoist: the hoist with adjustable speed control.

5. Hand winch: a winch that rotates the drum through a driving device with manpower as the power.

6. Large-tonnage non-standard hoisting machine: mainly used for lifting, pulling and unloading, pushing and dragging heavy objects.

Packing&Delivery

Package

1. Use the wooden box made of inspection free plates in line with export requirements, and use plywood with a thickness of 9mm-15mm.

2. The wooden box made of solid wood can meet the requirements of export through fumigation and detoxification.

3. boxes board joint is tight, the box board combination is smooth without dislocation, the cloth nail is reasonable, the reinforcement belt is not less than 2, to meet the requirements of the export.

 Our Services

portable winch used mini 230v electric winch wire rope capstan winch





Pre-Sales Service

♦ Inquiry and consulting support.

♦ Sample testing support.

♦ View our Factory.

After-Sales Service

♦ Engineers available to service machinery overseas.

♦ Training how to instal the machine, training how to use the machine.

Company Information

portable winch used mini 230v electric winch wire rope capstan winch

Henan hengtai company specializes in the production of various electric, hydraulic hoist;Single drum, double drum and triple drum friction winch;Fixed, mobile hoist, winch hoist, and customers according to the site tailored winch.As a company with rich practical experience and rich technical resources in the field of winch machines, we have been committed to providing customers with the most reliable products and the most intimate service. Our factory regards the product quality as the enterprise life all the time, obtains the long-term development by the prestige, the consummation examination method and the perfect quality guarantee system,lets each product all achieve the profession standard.Superb technology, first-class equipment, quality products,innovative science and technology concept is the source of enterprise life, but also to win the market advantage.
