Сварочный аппарат TIG 200A
US $152.00-$161.00
Tig donson импульсный легкий двойной Voltaje eelding электродная медная комплект электроды 0 5 мм 05 электролитической Er70S-6 Fe 8
- Категория: TIG Welder >>>
- Поставщик: Chengdu,Xingweihan,Welding,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 26527.58 $* | 27853.73 $* |
| Aug-16-2025 | 26305.28 $* | 27620.85 $* |
| Jul-16-2025 | 22069.31 $* | 23172.71 $* |
| Jun-16-2025 | 25859.46 $* | 27152.78 $* |
| May-16-2025 | 22515.88 $* | 23641.87 $* |
| Apr-16-2025 | 25413.66 $* | 26684.26 $* |
| Mar-16-2025 | 25190.50 $* | 26450.53 $* |
| Feb-16-2025 | 24967.87 $* | 26215.55 $* |
| Jan-16-2025 | 24744.23 $* | 25981.99 $* |
Характеристики
ChengDu Xinwei is one of the leading welding equipment manufacturer in china, Specialized in manufacturing and provide customers with a complete set of welding solutions.
A R&D team of more than 20 engineers., and a 20000 sq.m manufacturer, which guarantees that we can offer customers the most professional welding advice and after-sales service.
And we have our own overseas technical service teams in many countries in Southeast Asia and South America to provide customers with on-site installation and maintenance services.（Please contact us to ask if there is a technical team in your country）
![]()
![]()
![]()
![]()
![]()
A R&D team of more than 20 engineers., and a 20000 sq.m manufacturer, which guarantees that we can offer customers the most professional welding advice and after-sales service.
And we have our own overseas technical service teams in many countries in Southeast Asia and South America to provide customers with on-site installation and maintenance services.（Please contact us to ask if there is a technical team in your country）
Product Welding Video | We provide technical guidance videos, product welding videos, and samples please contact us. | ||||||
Overseas on-site technical team | South America, Southeast Asia,etc | ||||||
One-stop service | MIG / TIG / Spot welding machine / Seam welding machine / Welding robot / Suspended Transmission System / Controller / Spring Balancer / Electrode | ||||||
Models Item | DN-35 | DN-25 | DN-16 | DN-10 | |||
Rated Power at 50% | 35KVA | 25KVA | 16KVA | 10KVA | |||
Rated Primary Power | 380V | 380V | 380V | 380V | |||
Rated Primary Current | 92A | 66A | 42.1A | 26.3A | |||
Rated Duty Cycle | 10% | 10% | 10% | 10% | |||
Secondary Unload Voltage | 2.6～4.2V | 2.3～3.55V | 1.98～3.01V | 1.65～2.4V | |||
Adjustment Rated | 4 | 4 | 4 | 4 | |||
Welding Time Adjustment | 0～9.99s | 0～9.99s | 0～9.99s | 0～9.99s | |||
Arms Length | 280mm | 280mm | 280mm | 260mm | |||
Max. Welding Capacity | 3.5+3.5mm | 2.5+2.5mm | 2+2mm | 1.5+1.5mm | |||
Cooling Ways | Main Transformer: Air Electrode: Water | ||||||
Features | 1) The main transformer is made of imported cold-rolled silicon steel, less power loss and low no-load current. 2) Pivoting arm, pedal, spring press structure, easy to operate, The structure in graceful form, durable and cheap. 3) In main circuit adopts thyristors as non-contactor switch, quick switch off and reliable. Welding time can be controlled and adjusted precisely, good welding repeatability, easy to maintenance, can realize high quality weld. 4) Adopt the digital control system; it is widely used in mild steel, wire, stainless steel plate and so on. | ||||||
For more welding videos, please CONTACT US!
Packing&Shipping
![]()
Service
1. Any inquiries will be answered within 12 hours, we have been tilling in the welding equipment business for more than 17 years.
2. Professional welding project solution.
3, Detailed product usage technical guidance video.
4. Professional overseas on-site technical team.
5. After-sale service:
2. Professional welding project solution.
3, Detailed product usage technical guidance video.
4. Professional overseas on-site technical team.
5. After-sale service:
1) All products will go through strict quality check in our factory before packing, we have experienced QCteam who is in charge of quality checking before shipping.
2) All products will be well packed before shipping.
3) Our products have a 1-3 year warranty, and we are sure our products will be free from maintenance within the warranty period in general, even core components have lifetime warranty.
2) All products will be well packed before shipping.
3) Our products have a 1-3 year warranty, and we are sure our products will be free from maintenance within the warranty period in general, even core components have lifetime warranty.
XinWei Project
![]()
Company Profile
![]()
![]()
![]()
Chengdu Xinwei Welding Technology Co., Ltd is a high-tech corporation integrated with researching, developing, manufacturing,marketing and service. Our company was established in decades ago and produces resistance welding machine and relative products.
Now it is located in Eastern Industrial Zone, Xindu, Chengdu. Our machines were exported to Australia, Pakistan, Mexico, Italy, United Arab Emirates, Malaysia, Argentina, Jordan, Hongkong and other more 40 countries.
Our main product: Portable Spot Welder, Portable MF Spot Welder, Suspension Spot Welding Machine, Stationary Resistance Spot Welding Machine, Robotic Welding Gun, Nut Feeder, Micro-computer resistance controller,etc.
Now it is located in Eastern Industrial Zone, Xindu, Chengdu. Our machines were exported to Australia, Pakistan, Mexico, Italy, United Arab Emirates, Malaysia, Argentina, Jordan, Hongkong and other more 40 countries.
Our main product: Portable Spot Welder, Portable MF Spot Welder, Suspension Spot Welding Machine, Stationary Resistance Spot Welding Machine, Robotic Welding Gun, Nut Feeder, Micro-computer resistance controller,etc.
Certifications
![]()
![]()
![]()
Customer Audit
![]()
![]()
![]()
Exhibitons
![]()
![]()
![]()
![]()
FAQ
1. When can you arrange shipment?
We usually arrange shipment within 15 days after getting deposit, but customized machines should be more than 25 days. We always ship by air and sea in the mean time.
2. Do you inspect the finished products?
Yes, Each step of production products will be came out inspection by QC department before shipping.
3. Are you a factory?
Yes, We are a factory, all machine is made by ourselves and we can provide customize service according to your requirement.
4. What does your factory produce?
We produce and export all kinds of automatic welding machine and robots and relative parts. We can design machines according to your requirements.
5. What’ your warranty and after-sales?
We offer 1 year warranty, various forms of online instruction and the spare parts. Professional engineers will solve problem, if necessary.
6. How about your transport packing? Is it possible to damage the machine during the transportation?
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.
We usually arrange shipment within 15 days after getting deposit, but customized machines should be more than 25 days. We always ship by air and sea in the mean time.
2. Do you inspect the finished products?
Yes, Each step of production products will be came out inspection by QC department before shipping.
3. Are you a factory?
Yes, We are a factory, all machine is made by ourselves and we can provide customize service according to your requirement.
4. What does your factory produce?
We produce and export all kinds of automatic welding machine and robots and relative parts. We can design machines according to your requirements.
5. What’ your warranty and after-sales?
We offer 1 year warranty, various forms of online instruction and the spare parts. Professional engineers will solve problem, if necessary.
6. How about your transport packing? Is it possible to damage the machine during the transportation?
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.
