1600 C mini vacuum tube furnace horizontal small quartz compact tube furnace for carbonization lab
1600 C mini vacuum tube furnace horizontal small quartz compact tube furnace for carbonization lab
Dming vacuum tube furnace used high pure alumina or quart tube as furnace chamber. Working range is from 300℃ to 1600℃. Precise and advanced auto temperature controller, high temperature accuracy, easy operation, excellent heat-insulation effect, symmetrical temperature uniform, Brother tube furnace widely used in the labs of university and Research Institutions, also used in factory for production.
Standard specification:
Model
Dia* Heating
zone
Power
Max working temperature
Thermocouple
Furnace tube material
Heating elements
DM-16MT-40/300
40x300mm
4 KW
1600oC
B type
Alumina tube
MoSi2 Heater
DM-16MT-60/300
60x300mm
4 KW
DM-16MT-80/300
80x300mm
4KW
DM-16MT-100/300
100x300mm
6 KW
DM-16MT-120/300
120x300mm
6 KW
DM-16MT-40/450
40x450mm
5 KW
DM-16MT-60/450
60x450mm
5KW
DM-16MT-80/450
80x450mm
5KW
DM-16MT-100/450
100x450mm
7KW
DM-16MT-120/450
120x450mm
7KW
Product Features
l Max temperature: 1200℃ (HRE Fe-Cr-Al-Mo wire)
1400℃ (Sic Heater)
1600℃ (MoSi2 Heater)
l 50 segments programmable and auto control
l Furnace structure, double layer steel dual cooling fan, surface temperature below 50℃
l 304 stainless steel vacuum sealing flange
l Adjustable flange support structure at both ends to extend furnace tube life
l Over-temperature protection function, automatic power-off when the temperature exceeds the allowable set value
l Safety protection: Automatically power off when the furnace body leaks
l Heating rate <=20℃/min
l Temperature accuracy ±1 ℃
l Max vacuum -0.1MPa
l Configuration molecular pump, Vacuum 7x10-4Pa
1600 C mini vacuum tube furnace horizontal small quartz compact tube furnace for carbonization lab
Why Choose Us
Production&Inventory
Packaging & Shipping
FAQ
Q1. How is your company's product after-sales service system? A: We have professional pre-sales and after-sales departments that can respond to you within 12 hours to resolve any technical issues. Q2. How about the quality guarantee period? A: 2 years, exclude irrationally operating and consumable parts. Q3. How about your products quality? A: CE certification available and twice test before shipping. Q4. What's your delivery time? A: Under normal situation 3 days. 35 Days for customized products. Q5. Are you a manufacturer or a trading company? A: We are a factory with 10 years experience in the field.
