Небольшая пиролизная установка для отработанных шин хорошего качества

Application

1. Heating material : sell to cement factory, glass factory, ceramic factory, electric power factory, steel making factory ,
boiler factory, etc.
2. Used for heavy oil generator for electricity generation.
3. Deep process it into diesel oil by oil distillation machine, then can be used in cars , trucks, tractors, etc.

1. Make it into pellet or briquette as heating material.
2. Make it into N220, N330, N550 or N660 which is widely used in tire making industry.
3. Make it into plastic grains then sold to plastic industry.

1. Sell it to iron and steel factory directly.
2. Sell it to steel distributors.

1.Recycled into furnace to heat reactor instead of coal/wood/oil/natural gas.
2.Store it then supply the pyrolysis equipment heating ,it’s recycling.

No.

Items

Contents

1

Input-Raw Materials

Waste tire/rubber/plastic/Medical waste/municipal solid waste/waste organic glass

2

Final products

Fuel oil, carbon black, steel wire,flammable gas.

3

P/N.

LES-2600*6600

4

Capacity/24h

10Ton/Batch

5

Oil production(T)/24h

4

6

Power(KW)

5.5

7

Cooling water(T/h)

6

8

Rotate speed(r/min)

0.4

9

Heating type

Direct heat

10

Cooling type

Water-cooled

11

Noise(dB)

<=85

12

Operating

Intermittent

13

Driving mode

External gear

14

Reactor material

Q345R

15

Structure

Horizontal rotation

16

Host weight(T)

26

17

Reactor size(mm)

Ø2600*6600

18

Combustion value

35-50m3

19

Certification

CE ISO SGS BV

20

Land request

300-400㎡

21

EU emission standard

100% non-pollution
