About filter press to treat wastewater

Jack press filter is a kind of intermittent pressure filtration equipment,uses screw jack as a pressing device,It is suitable for variety suspension's solid-liquid separation.

1.Simple structure

2.Easy operation

3.No need power support

4.Economical and practical

5.Cheap price

Structure of jack filter press

1. Filter press consist of frame ,filter plate ,pressing system

The frame can be wrapped with stainless steel if customer need

The filter plate can be chamber type ,or diaphragm squeezing type

The pressing system is manual jack screw type.Except for manual jack screw type, we also supply manual hydraulic type, automatic hydraulic type

2. For manual jack screw type , The filter area is more suitable for 1-40 square meter

3. The volume of filter chamber :15-600L

4. Filter pressure can be 0.6Mpa

5. The filter plate can undertake temperature 0-120 ℃

Working principle of manual jack screw press filter

The filter plates are closed together under pressure,and then formed filter chamber. Press the material into the chamber with feeding pump until filter cake formed with lower moisture content.Discharge the filter cake ,finish separating solid and liquid.

The manual jack screw filter press can make the function ,such as diaphragm squeezing , cake washing, compressed air purge, etc.

Application of filter press ,The filter press can separate most kinds of suspension liquid, achieve solid -liquid separation effect

1.Sewage treatment

Printing and dyeing wastewater, sewage, smelting, leather, pharmacy sewage water brew, electroplating wastewater, sewage and waste, chemical electrolysis of water environment etc.

2.Chemical industry

Coating, paint, silica, caustic soda, soda ash, alkali, salt mud (aluminum, aluminum polymerization acetylacetonate, gypsum, insurance, phosphor) etc.

3.Food industry

Vegetable oil, starch sugar, plant sweet, maltose, starch, maize, seaweed, kara glue, oral liquid, beer yeast, rice wine, white wine, fruit juice, beverage, plant protein etc.

4.Pharmacy industry

Phytic acid, calcium, Chinese traditional medicine, growth hormone, organophosphate etc.

5.Metallurgy, coal industry:

Gold, silver, copper, zinc ore mineral powder, etc

6.Other solid liquid separation industries.

Parameter of jack screw filter press for your reference , we also can do customized filter press

NT~(6A5L%UJBK$I$%(VAI.png" ori-width="661" ori-height="429"/>

Part models ordered by our customer

1. XQ3-320. Filter aera 3 square meter, filter chamber 46L



2.XQ30-630,filter aera 30 square meter,filter chamber 452L





3.XQ6-450  filter area 6 square meter , filte chamber 91L



The filter plate can be chamber and membrane



For small filter press , we will packed in exporting wooden box



The related filter press we supply







Filter cloth manufactured by own factory , control the quality strictly





We own partners of pump manufature , if you need , we can supply you as your demand



 The service we offer

1. Help customer select suitable model based on material features and processing capacity

2. We do customized model and offer spare parts any time you need

3. We only manufacture filter press , if you need pump , we also can help you purchase

4. We manufacture filter press machine and filter cloth , supply different precision and material filter cloth

5. we offer operation guidance and after-sale service

6.If you want to visit our factory ,Please fly to air port xinzheng ,china ,  we will pick up you and take you to our factory to know product and learn operation technology

 Our factory ability

1. Manufacture experience,

Since 1997, we have done a lot of innovation and improvement in the field of filter and separation equipment. We are specialized in design of the filter press according to clients’ requirments, the delivery time of a filter press can be 7 days(if no stock).

2. Technology capacity,

We join and make the standard of filter press industry in China, All of our products have CE certificate, also they will be tested before delivery.

3. Our superiority,

We are in the first class in the field of filter press of China, more than 250,000 m2 land area and continue developing. Filter areas of filter press widely ranges from 1 m2 to 500 m2, you can always choose a right type.

About us

Zhengzhou Toper is the leading supplier of industrial equipment in China, and also the professional exporter and service provider of filter and separation equipment.
More than 250,000 square meter land area and continue developing.
We have been in this field and Alibaba gold supplier for more than ten years.We focus on full service for filtering project from design to after-sales service .Zhengzhou Toper has supplied products and service over 200 enterprises excluding China mainland.
Welcome to contact us and experience our filter equipment and service.
