B21-00 супермаркет штрих-код для рабочего стола 2D штрих-кода сканер модуль с широкими окна розничного магазина
- Категория: Термический фотоаппарат и беспроводным способом по Bluetooth >>>
- Поставщик: Shenzhen,Edoo,IOT,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 14.84 $* | 15.68 $* |
| Aug-17-2025 | 14.24 $* | 15.44 $* |
| Jul-17-2025 | 12.29 $* | 13.4 $* |
| Jun-17-2025 | 14.2 $* | 15.12 $* |
| May-17-2025 | 12.71 $* | 13.5 $* |
| Apr-17-2025 | 14.36 $* | 15.61 $* |
| Mar-17-2025 | 14.90 $* | 15.11 $* |
| Feb-17-2025 | 13.56 $* | 14.53 $* |
| Jan-17-2025 | 13.96 $* | 14.66 $* |
Характеристики
Specification
B21-10/Barcode Scan Box
Image Sensor | CMOS | ||
Pixel | 640*480CMOS | ||
Symbologies | 2D | PDF417, QR Code,Data Matrix | |
1D | QR,CODE128,CODE39,ENA13,EAN-8, UPC - A,UPC-E0,UPC-E1,ITF | ||
Reading Window | 75mm x 60mm | ||
Code Sensitivity | Skew | ±50°@ 0°Roll and 0° Skew | |
Roll | ±360°@ 0°PitcB21-10 and 0° Skew | ||
Pitch | ±45 °@ 0°Roll and 0° PitcB21-10 | ||
Lowest Contrast | ≥30% | ||
Data Interface | USB B21-10ID-KBW | ||
Typical depth of view | code39_14 | 20-110mm | |
code128_19 | 20-125mm | ||
WeChat Code | 20-145mm | ||
Physical | Size(L*W*H) | 150mm x 95mm x 95mm | |
Weight | 220g | ||
Indication | White LED | Even Illumination | |
Beeper | Sound of scanning output | ||
Operation Voltage | 4.5-5V | ||
Operation Current | Beep value: 240mA, idle: 65mA | ||
Rated Consumption | Beep value: 1200mW,idle: 325mW | ||
Operation Temperature | -10℃~+60℃ | ||
Storage Temperature | -30℃~+70℃ | ||
Relative Humidity | 5%~95%(Non-condensing) | ||
Static Protection | ±12 kV(Air discharge),±8 kV(Direct discharge) | ||
Protection Level | IPX4 | ||
Software Compatibility | Windows,android | ||
Accessory List | 1.5m USB cable, to power on and transmit the data |
Features:
Outstanding Reading Function
Adopt the self-developed core decoding technology, quickly read various 1D and 2D bar codes.
LED and Beeper Function Together
LED light adds the stronger illumination for easier reading, beeper signals for reading successfully or not, even in the noisy environment.
Ultra Wide Reading Window
145mm reading distance, 110mm/s movement tolerance, to meet the close bar code reading of mainstream cell phones.
Speedy Multiple Scanning
Support quick reading and continuous quick reading of cell phone, support quick reading of 2D bar code on paper
Scenarios:
Supermarket/retail shop cashier, vendor booth, customer service center, ticketing vending/verification point, QR code e-payment of AliPay/WeChat Pay
Product Description
Recommend Products
Company Profile
SHENZHEN EDOO-IOT TECHNOLOGY CO., LTD
1D/2D QR Barcode Scanners and PDA Export
OEM and ODM orders accepted | Experienced export specialist and logistics experts
A Professional and Experienced Barcode Scanner and PDA Provider
Edoo-IoT Technology is an IoT exporter and manufacturer located in Shenzhen. We can provide 1D & 2D laser/image barcode scanners, handheld barcode scanners, wireless barcode scanners, barcode scanning engines/modules, fixed/embedded scanners, desktop scanners, PDA smartphones or computers, barcode scanning platforms, and other scanning devices and technical services.
OEM and ODM orders accepted | Experienced export specialist and logistics experts
A Professional and Experienced Barcode Scanner and PDA Provider
Edoo-IoT Technology is an IoT exporter and manufacturer located in Shenzhen. We can provide 1D & 2D laser/image barcode scanners, handheld barcode scanners, wireless barcode scanners, barcode scanning engines/modules, fixed/embedded scanners, desktop scanners, PDA smartphones or computers, barcode scanning platforms, and other scanning devices and technical services.
Barcode scanning solution terminator for 6 years, amount of stock, ready to ship,QR code scanner, OCR/MRZ scanner
Office Area 1
Office Area 2
Our Advantages
Production Workshop
Production Equipment
Clean Room of Workshop
Workshop
Warehouse
Packing & Delivery
FAQ
Q1. What is the advantage about your company?
A1. Our company has professional team and professional production line.
A1. Our company has professional team and professional production line.
Q2. Why should I choose your products?
A2. Our products are high quality and low price.
A2. Our products are high quality and low price.
Q3. Any other good service your company can provide?
A3. Yes,we can provide good after-sale and fast delivery.
A3. Yes,we can provide good after-sale and fast delivery.
