Машина для выдувания полиэтиленовой пленкой

Машина для выдувания полиэтиленовой пленкой

Категория: >>>
Поставщик: Donglong,Plastic,Machinery,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	0.58 $*	0.38 $*
Aug-15-2025	0.58 $*	0.4 $*
Jul-15-2025	0.56 $*	0.67 $*
Jun-15-2025	0.98 $*	0.66 $*
May-15-2025	0.52 $*	0.97 $*
Apr-15-2025	0.1 $*	0.94 $*
Mar-15-2025	0.13 $*	0.49 $*
Feb-15-2025	0.33 $*	0.84 $*
Jan-15-2025	0.38 $*	0.62 $*

Характеристики

Product Overview

USES

The film blowing machine/film blowing machines/film blowing machinery/plastic film blowing machinery is used to produce the mulch
plastic film, agricultural film and outer
package film made of low density polyethylene (LDPE), high density polyethylene
(HDPE), linear low density polyethylene (LLDPE) and metallocene linear low density
polyethylene (LLDPE). This kind of film blowing machines employs some new technologies like the most advanced heat running technology and special wind ring that is used to extrude the shaped
mulch plastic film. The film blowing machines is designed reasonably and elegantly. It is
small and is easy to operate and maintain. The product features with good
plasticization, high physical and mechanical performance and strong tear resistance.

FEATURES AT A GLANCE

1) This film blowing machines is designed to produce plastic film made of low density
polyethylene (LDPE), high density polyethylene (HDPE), linear low density polyethylene (LLDPE).
2) The pe film blowing machine is designed reasonably and elegantly. It is small and is easy to operate and maintain.
3) With high output, low energy consumption, good stability and reliability.
4) The film are widely used in application of package of civil and industrial products such as food, garment, textile and daily
necessities etc. It includes vest bag, shopping bag, garment bag and food bag.

Right elevation

Left elevation

Front elevation

PRODUCT CONFIGURATION

Main technology parameters:
Model No.:SJ35-FMS500P

1)Layer number:one layer
Max.Flim Width:400mm
Film Thickness:0.008-0.10mm
Raw Material:HDPE
Output:20kg/h

2)EXTRUDER
Screw Diamter:Φ35mm
Screw L/D:28:1
Heater Capacity:8.9kw
Driving Motor:5.5kw

3)DIE:
Die Diameter:Φ30mm,Φ
Heater Capacity:3.45kw
Cooling Blower:075kw

4)Haul-off:
With embossing roller(HDPE)
Driving Motor:0.75kw
Take-up Speed:10-70m/min
Winder Drive Motor:1.5kw
Temperature Control:5 units
Whole Power With Total Machine:About 21kw
Shape size:(L x W x H)3.5X2.5X3.0M
Weight:about 1.5t

SALES AND SERVICE NETWORK

SIMILAR PRODUCTS

FAQ

A:Where is our factory?
We are in Quanzhou city,Fujian,China
B:How to get to our factory?
(1)You can get to the Jinjiang airport directly,then,connecting us and we will pick you up by car
(2)You can take the train to Quanzhou station,then,we will pick you up by car
C:Why choose us?
(1)We have complete system of designing of our equipment
(2)We can provide the perfect management solutions
(3)We could make you in a leading position in the industry
D:What's the payment method?
L/C,T/T,Western union
E:Can we see the running machine in ur factory?
Yes.Before making your decision buying the equipment or not,you can bring some material here to test-run the equipment
F:How long of the warranty time?
Our warranty period is 1 year
