Онлайн Ups источник питания высокочастотный однофазный онлайн UPS Pure Sinewave 3kva
- Категория: Uninterrupted Power Supply (UPS) >>>
- Поставщик: Foshan,Xinchen,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 108.27 $* | 110.69 $* |
| Jul-18-2025 | 88.14 $* | 90.72 $* |
| Jun-18-2025 | 106.73 $* | 108.44 $* |
| May-18-2025 | 105.71 $* | 107.22 $* |
| Apr-18-2025 | 84.66 $* | 86.96 $* |
| Mar-18-2025 | 104.75 $* | 106.17 $* |
| Feb-18-2025 | 103.97 $* | 105.80 $* |
| Jan-18-2025 | 102.7 $* | 104.29 $* |
Характеристики
Product Description
Specification
MODEL | 3KVA(L) plus | |
PHASE | Single phase with ground | |
CAPACITY | 3000VA/2400W | |
INPUT | ||
Nominal Voltage | 110Vac | |
Voltage Range | 60-138VAC ±5% at 50% load 80-138VAC ±5% at 100% load | |
Frequency Range | 40Hz-70Hz(46-54Hz default 50Hz;56-64Hz default 60Hz) | |
Power Factor | ≥0.99@nominal voltage(100% load) | |
THDi% | ≤10% | |
OUTPUT | ||
Output Voltage | 100/110/120/127 VAC | |
AC Voltage Regulation | ±2% | |
FrequencyRange (Synchronized Range) | 47-53 Hz or 57-63 Hz | |
Frequency Range(Batt.Mode) | 50 Hz±0.1 Hz or 60 Hz±0.1 Hz | |
Current Crest Ratio | 3:1 | |
Harmonic Distortion | THD (Linear Load)≤4%,THD (Non-linear Load)≤7% | |
Transfer Time | AC to DC | zero |
Inverter to Bypass | 4ms (Typical) | |
ECO to Battery Mode | 8ms (Typical),10 ms (max) | |
Waveform | Pure Sinewave | |
EFFICIENCY | ||
Line Mode | ≥91%@battery full charged | |
ECO Mode | ≥96%@battery full charged | |
Battery Mode | ≥86% | |
BATTERY | ||
Battery Type | 12V/7AH | |
Numbers | 8 | |
Typical Recharge Time | 5hours recover to 95% capacity for internal battery | |
Charging Current | 3KVA 1A 3KL 4.5A | |
Charging Voltage | 110VDC±1% | |
INDICATORS | ||
LCD Panel | Load level,Battery level, AC mode,Battery mode,Bypass mode,and Fault indicator | |
ALARM | ||
Battery Mode | beeps every 5 seconds | |
Low Battery | beeps every 2 seconds | |
Overload | Beeps every seconds | |
Fault | Continuously beeps | |
PHYSICAL | ||
Dimension,D*W*H(mm) | 425*190*328 | |
Net Weight(long backup )(kgs) | 12 | |
Net weight (w/built-in batteries)(kgs) | 28 | |
ENVIRONMENT | ||
Humidity | 20-95%RH@0-40℃(non-condensing) | |
Noise Level | Less than 50dBA @ 1 Meter | |
MANAGEMENT | ||
Smart RS-232 or USB | Support Windows2000/2003/XP/Vista/2008,Windows7/8/10,Linux and MAC | |
Optional SNMP | Power management from SNMP manager and web browser | |
STANDARD | ||
EMC/Safety | EMC EN62040-2 C2 for CE models | |
