Оригинальная Подлинная горелка Riello G5LC G10LC G20LC G5 G10 G20
US $486.00-$745.00
Промышленный Газовый легкий дизельный одноступенчатый бойлер аксессуары
- Категория: >>>
- Поставщик: Henan,Yuji,Boiler,Vessel,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 1190.67 $* | 1250.52 $* |
| Aug-15-2025 | 1180.3 $* | 1239.80 $* |
| Jul-15-2025 | 990.18 $* | 1040.44 $* |
| Jun-15-2025 | 1160.31 $* | 1218.37 $* |
| May-15-2025 | 1010.49 $* | 1061.20 $* |
| Apr-15-2025 | 1140.48 $* | 1197.37 $* |
| Mar-15-2025 | 1130.10 $* | 1187.15 $* |
| Feb-15-2025 | 1120.22 $* | 1176.18 $* |
| Jan-15-2025 | 1110.50 $* | 1166.0 $* |
Характеристики
Product Description
Industrial Gas Light Oil Diesel One Stage Boiler Accessory Oil Fired Burner
Different from integrated burner, a split burner consists of two modules:
1)Burner fuselage and head;
2)Independent blower.
These two modules are connected by air pipes to form a complete burner system. Benefits of independent blowers:
1)Burner fuselage and head;
2)Independent blower.
These two modules are connected by air pipes to form a complete burner system. Benefits of independent blowers:
Blowers can be installed in workshops different from burners, such as basements, which can reduce the noise of boiler rooms. When the blower is installed in the same workshop, it is necessary to make a muffler outside the blower to reduce the noise without blocking the arrangement of the burner.
-Split burner occupies less space in front of the boiler.
-The split burner also reduces the load on the front wall of the boiler.
-The blower can be installed according to any type, and can overcome the resistance of the back pressure or heat exchanger of the combustor by using the existing ventilation equipment, which fully meets the requirements of users and industrial applications.
-The combustion-supporting air can be heated up to 250 degrees, and the operation efficiency of the system can be improved.
PS: All TS series burners need to be equipped with a blower. If the regulation ratio is above 1:6, a corresponding motor frequency converter can be configured to increase the regulation ratio to the burner. When the low nitrogen emission requirement is below 30 mg/kWh, a mixing box can be installed at the entrance of the fan. The mixing box is connected with the regulating valve of the flue gas pipeline, and the suction of the blower is used to mix part of the flue gas with air and feed it into the burner. At this time, the nitrogen oxide emissions of the burner will be reduced.
| Material | Cast iron, Cast steel or customer's request |
| Output power | 23-70 KW |
| Size | Customized design |
| Brand | YUJI |
| Remarks | Customized order is also accepted. |
Related Products
Packaging & Shipping
Company Information
Henan Yuji Boiler Vessel Co., Ltd. is the general administration of quality supervision, inspection and quarantine of the People’s Republic of China approved the boiler and pressure vessel designated manufacturing enterprise, The company passes ISO 9001 international quality system certification, and gains the EU CE and other international certification ect.
We ensure the quality of our products with our life. Quality assurance systems are set, include the design production, technology management, material experiment, welding control, inspection and audit, measurement and production management. The technology center has enterprise cooperation relationship with Many famous universities in China, leading the industry with innovation and new technology, and building a strong research and development system.
Customer Feedback
FAQ
Q. Are you manufacturer?
A: Yes, we are professional manufacturer of boiler and pressure vessels in Henan, China.
Q: Do you have any Certificate?
A: Yes. Our boiler have got China GB ISO certificates and CE certificate of EU. We also can provide ASME, GHOST and other necessary certificates if you need.
Q: How can I pay you?
A: T/T, Western Union, Money Gram and Ali Trade Assurance is better.
Q: What about the delivery time?
A: 5-10 working days for single machine, and 30-40 working days for bulk order and door to door delivery service is also available.
Q. What about the warranty?
A: We provide 1 year warranty for free and life-long time maintenance
Q. What about installation?
A: We provide 1 or 2 technicians overseas services for installation, debugging and training.
Q. What about the boiler fuel?
A: We provide boiler can use coal, charcoal, wood, rice husk, straw, biomass pellet, diesel, light oil, natural gas, city gas, liquefied gas etc.
