Product introduction:

This machine is suitable for non woven fabric material only, it is the most advanced equipment and has the function of full automatic handle loop sealing. The speed is about 20-120 pcs/min,Handle bag making speed is 20-55pcs/min, it equals to 6 workers operating 6 handle sealing machines. It can fully automatic make non woven bag products with different bag type and size, as handle attached bags, T-shirt bags (vest bags), box bags, flat bags, drawstring bags and so on. It has widely used in clothing, footwear, wine, gifts packaging etc. The machine can instead of the traditional hand-sewing and reducing labor and manufacturing costs. It’s very popular in worldwide.





Features:

1. This machine adopts Taiwan touch screen computer display, PLC computer program which can be edited.
2. Auto meter counting &stopping, could freely setting number.
3. Computer Fixed-length, printing color mark track orientation, Auto-stop when complete.
4. High voltage static processor, Auto constant temperature heating controller.
5. This machine has the function of automatic punching.

6. Unwinding magnetic powder tension control with manual, Auto side-correction control.
7. This machine adopt ultrasonic welding of all aspects, bag mouth folding welding, side sealing, once full completed, fast speed, easy to operate, firm sealing, beautiful and decent.



Main Technical Parameter

Non Woven Bag Making Machine Type	TYG-700(5 in 1)
Production Speed	20-120pcs/min
Bag Width	100-800mm
Bag Length	200-600mm
Bag-Making Thickness	20-120g
Power Supply	380V/220V
Total Power	18KW
Overall Dimension (L*W*H)	10.3m*2m*2.1m
Weight	3500KG

Horizontal  traction unit	One set
Vertical fold unit	One set
Blanking way	Magnetic  powder  tension controller
Roller control device	Air Shaft φ3″(φ76mm)
Roller diameter	φ1000mm
Correcting deviation device	Automatic correcting deviation system
Automatic shutdown system	Photoelectric eye
Plate	Stainless steel
Power control system	Special motor tension driver system
Ultrasonic  system	Side  Sealing   300mm 2 pieces(Taiwan Mingyou) Lace Roller Sealing70mm 2 pieces T-shirt  Bag       70mm 1 piece
Temperature control system	Temperature control unit
Operation	man-machine interface touch control
Relay	Omron
Pneumatic component	Sns
Temperature gauge	Yueqing Wenzhou China
Switch	Chint
Inverter	Defu from Taizhou
converter motor	Shengbang(made in Taiwan)
Main Touch Screen	Chinese(PLC)
Bearing	Haerbin

Samples:









If you want to make T-shit bag, you need to add the auto punching machine.









TY-530 Hydraulic Pressure Manual Punching Machine
