High precision laser welder molds repair desktop yag laser welding machine for sale
Product Paramenters
Model | DW-Y200 laser welding machine |
Max. laser power | 200W/400W(optional) |
Laser wave length | 1064nm |
Range of adjustable power | 1-100% |
Laser spot size adjusting range | 0.1-3mm |
Repeat frequency | 5-10KHz(adjustable) |
Pulse Width | 0.1-15ms |
Repeat precision | ±0.01mm |
Power stability | ±2% |
Length of fiber-optical | 5m |
Whole power consumption | ≤12KW |
Module life | >100000hrs |
Power supply | 220V±10%/50HZ 380V±10%/50HZ |
Main Advantages:
1.adopted UK imported ceramic condenser cavity, corrosion resistance, high-temperature resistance, long service life.The laser power feedback control system to ensure the stability of laser energy output. 2.Motic microscope observation operation, small parts at a glance.LCD interface, current, pulse width, frequency display function, dial to adjust the work table, more convenient for operation.
3.Device is equipped with high-definition CCD and red double-positioning systems, higher positioning accuracy.
4.X/Y platform design sports flexible, able to complete a one-time combination welding curves, straight, single-point and other complex processes. Joystick control, work can be any arbitrary curve to move.
4.X/Y platform design sports flexible, able to complete a one-time combination welding curves, straight, single-point and other complex processes. Joystick control, work can be any arbitrary curve to move.
5. The diameter of the laser welding point is adjustable, and the laser welding has high precision and high accuracy.
6.The machine can welding narrow place, deep cavity repair welding, will not hurt the surrounding wall. It will not deform the mold product or sink around the weld pool.Make up for the shortcomings of traditional argon arc welding, cold welding in the repair of the fine surface of the welding, oxidation efficiency is low, the work does not change color.
7.Special argon gas protection, control system can freely adjust the inlet and outlet time, repair welding site and substrate will not burn oxidation.When welding fine corners, it will not burn edges.
Product Description
High precision laser welder molds repair desktop yag laser welding machine for sale
Motic HD microscope：
10 x microscope amplification,cross cursor indicator,and adopting advanced automatic shading system.synchronization with the laser output of shielding gas,to make sure the solder joints and beautiful and smooth.
CCD Camera:
Adopts China famous brand CCD camera,LCD screen and red pointer. CCD camera can photo-shot the welding details and transmit the signal to LCD screen.The welding effect is more clear and intuitive.
X / Y / Z three-axis mobile work platform：
Electric lifting for the working table,fixed focus more quickly.X/Y platform design sports flexible, able to complete a one-time combination welding curves, straight, single-point and other complex processes.
Laser Head:
The laser head can rotate 360 degress,which is much more convenient for positioning and welding for the special-shaped objects.
LCD Colorful Screen:
The operation interface of the welding machine control system is simple and practical.Pulse width, frequency and speed can be adjusted on the screen and no need PC. Can save 50 sets of frequently used welding parameters. easy to use.
Double LED Light:
Standard comes with 2 high-light camera auxiliary lights, a white CCD auxiliary light, and a blue microscope auxiliary light. The auxiliary lighting uses energy-saving high-light bulbs with clear imaging and good heat dissipation effect,and will not burn the
skin for a long time.
Safety Foot Pedal:
Protective foot switch can prevent the switch from being touched by mistake.
