Новый Huawei SmartAX EA5801 серии EA5801-GP08 EA5801E mini olt
US $389.00-$700.00
Новинка 90% б/у Ma5608t Ma5683t Gpon Epon Olt низкая цена хорошая
- Категория: Telecommunications >>>
- Поставщик: Zhengzhou,Youma,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.62 $* | 0.75 $* |
| Aug-16-2025 | 0.19 $* | 0.31 $* |
| Jul-16-2025 | 0.24 $* | 0.21 $* |
| Jun-16-2025 | 0.90 $* | 0.20 $* |
| May-16-2025 | 0.84 $* | 0.1 $* |
| Apr-16-2025 | 0.14 $* | 0.73 $* |
| Mar-16-2025 | 0.66 $* | 0.3 $* |
| Feb-16-2025 | 0.2 $* | 0.62 $* |
| Jan-16-2025 | 0.23 $* | 0.64 $* |
Характеристики
90% new second hand ma5608t ma5683t gpon epon olt lower price good compatibility
Product Description
The MA5608T has a strong adaptability to the environment and can be deployed quickly. In FTTx networks, the OLT is moved closer to the user side, which can save backbone optical cable resources. This solves the problem of a few users and long access distance, when FTTx services are applied in an area with a low population density.
Model No. | MA5680T | MA5683T | MA5608T |
Dimension: | 490*275.8*447.2mm | 442*283.2*263mm | 442*233.5*88mm |
Operating Environment | Temperature: -25℃~+55℃ Humidity:5%~95% (non-condensing) | Temperature: -40℃~+65℃ Humidity:5%~95% (non-condensing) | Temperature: -40℃~+65℃ Humidity:5%~95% (non-condensing) |
Power Supply Parameters | -48V DC input Supports dual power protection Working Voltage range -38.4V~-72V | -48V DC input Supports dual power protection Working Voltage range -38.4V~-72V | -48V DC input Supports dual power protection Working Voltage range -38.4V~-72V Support 220V / 110V AC input |
Backplane Exchange capacity | 3.2Tbit/s | 1.5Tbit/s | 720Gbit/s |
Control Board Exchange Capacity | 1920 Gbit/s | 960Gbit/s | 512Gbit/s |
Access Capacity | 128*10G EPON 64*10G GPON 128*EPON 256*GPON 768*GE | 48*10G EPON 24*10G GPON 48*EPON 96*GPON 288*GE | 16*10G EPON 8*10G GPON 16*EPON 32*GPON 96*GE |
Access Type | Upstream interface: 10GE optical, GE optical/electricity Business interface: EPON optical port, GPON optical port, 10G EPON optical port, P2P FE optical port, P2P GE optical port, Ethernet optical interface | ||
System Performance | Layer 2 / Layer 3 wire-speed forwarding Support static router /RIP/OSPE.MPLS BITS/E1/STM-1/Ethernet/1588v2/1PPS+ToD clock Maximum support 1:256 splitting ratio Maximum support 60KM logical distance | ||
MA5608T configuration:
2 MCUD of control and uplink integreated board(MCUD1 10G Uplink for Option)
1 MPWD AC & DC Power Board OR 1 MPWC Dual DC power board (AC to DC Power Converter have to buy separate)
1 GPON or EPON 8 ports board with 8 Modules; (GPFD EPFD 16Ports for Option)
Acessories: Power cable, earth cable, patchcords, banding ribbon, screws etc
