Микро пузырчатая воздушная аэрационная трубка диффузор для аквариума/креветок пруда сельского

Описание и отзывы

Трекер стоимости

Характеристики

Name	Micro bubble air aeration tube diffuser for fish tank/shrimp pond farming
Material	EPDM Membrane + PP Inner tube
MOQ	1 piece
Size	500mm( 65mm*Any size)
Package	24pcs/ctn
Payment	T/T
Delievery Time	3-15days



HMT	Length 500mm	Length 750mm	Length 1000mm
Service area	0.5-1.5m2	0.75-2.25m3	1-3m3
Air flow	1.5-5 m³/h	2.25-7.5m³/h	3-10 m³/h
Oxygen utilization	27%-38%	27%-38%	27%-38%
Resistance loss	1900-3000 pa	1900-3000 pa	1900-3000 pa
Temperature	0-80℃	0-80℃	0-80℃
Membrane thickness	2±0.1mm	2±0.1mm	2±0.1mm
Perforation quantity	17000	17000	17000
Perforation size	1mm	1mm	1mm
Bubble size	1-2mm	1-2mm	1-2mm



 1. The rubber washer and the corresponding groove are designed to ensure the air tightness of the product.   Instead of using raw tape in the installation process, it is convenient to install, stable and reliable.

 2. Check valve structure. When operation stops, the membrane covers the structure under the action of   rebound force and water depth pressure to prevent the backflow of mud water.

 3. Mechanical assembly production line, hot welding instead of adhesive process, to ensure adequate supply,   uniform product quality, stable and reliable.

 4. The spanner position is designed. Spanner is used to replace the traditional hand-twist installation, avoid   membrane damage. And installation is convenient and reliable.

 5. Product adopts single-ear pole clamp which make product bear 360 degree uniform stress. Under heat   expansion and contraction as well as vibration, it can play a spring regulating effect. All single-ear clamps   are 316 stainless steel material. It is more reliable in sewage.

 6. Six channel design, increase ventilation cross - sectional area, reduce resistance, efficient and energy -   saving. The multiple positions of the membrane jointly bear air friction, reduce local wear and extend aerator membrane service life. Also, promote product 360 ° aeration, improve the product efficiency.



Fine bubble air diffuser is the only product that we do because we want to be concentration and profession. Besides of manufacturing product, we also do aerobic plant calculation and project design. Also, we make construction in domestic market. With projects feedback, we improve product continuously to solve different problems.

Jiangsu Huanchuan Environment Engineering Co., Ltd. is a specialist supplier of fine bubble air diffuser for  wastewater treatment. Based in Jiangsu Taizhou and supplying products across the world, yearly waste water treatment project experience helps us to improve product persistently.

 -Concentrate on fine bubble diffuser only.

 -Our founder has over 10 years experience in rubber.

 -As manufacturer, we have strong control in product quality and without middle man price.

 -Philosophy of right product first, then right price.

Q: Hello! I have some questions that you need to help me answer, can I?

A: Yes, I am very happy to answer your question.

Q: What is the acceptable MOQ?

A: Two cartons for minimum order quantity.

Q: What is the delivery time?

A: For sample, we usually have stock, so the delivery time will be quite short.

For normal order, the delivery time should be in two weeks.

Q: What is acceptable pay term?

A: T/T.

Q: Do you provide sample?

A: We can offer free sample for test, and customer needs to pay the freight charge.

Q: Thank you for your answer.

A: I am very happy to serve you!
