Крупноформатная машина для печати обоев YC2030L цифровой
- Категория: Printing Shop Machines >>>
- Поставщик: Linyi,Win-Win,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 14280.7 $* | 14994.41 $* |
| Aug-18-2025 | 14160.35 $* | 14868.28 $* |
| Jul-18-2025 | 11880.3 $* | 12474.27 $* |
| Jun-18-2025 | 13920.62 $* | 14616.40 $* |
| May-18-2025 | 12120.57 $* | 12726.22 $* |
| Apr-18-2025 | 13680.59 $* | 14364.82 $* |
| Mar-18-2025 | 13560.22 $* | 14238.19 $* |
| Feb-18-2025 | 13440.4 $* | 14112.58 $* |
| Jan-18-2025 | 13320.62 $* | 13986.18 $* |
Характеристики
Product Description
Specification
Product Model | YC2030L |
Printhead Technology | Drop-on demand piezo electric |
Printhead Control | Printhead voltage is software adjustable |
Printhead Type | RICOH GEN5/GEN6 |
Printhead Number | 2-8 |
Ink Characteristics | UV Curing Ink |
Ink reservoirs | Refillable on the fly while printing/1000ml per color |
Lamp | UV LED lamp |
Color Control | ICC based color, curves and density adjustment |
Printhead Arrangement | C M Y K LC LM W varnish optional |
Cleaning System | Positive Pressure Cleaning |
Guide Rail | Taiwan HIWIN |
Working Table | Vacuum Sucking |
Printing Size | 2000*3000mm |
Print Interface | USB2.0 |
Media Thickness | 0-100mm, higher can be customized |
Print Resolution | 300*900dpi,600*600dpi,600*900dpi,600*1200dpi |
Printing Speed | 15sqm/h-30sqm/h |
Life of Printed Image | 3 years(outdoor),10years(indoor) |
File Format | TIFF,JPEG,Postscript3,EPS,PDF etc. |
RIP Software | UltraPrint/ Photoprint/RIP PRINT optional |
Power Supply | 220V 50/60Hz(10%) >15A |
Operation Environment | Temperature 20 to 28℃, Humidity 40% to 60% |
Machine Dimension | 4000*3600*1450mm |
Packing Dimension | 3700*840*640mm , 4150*2240*1550mm |
Weight | 1500kg |
Warranty | 12 months exclude the consumables |
Japanese imported Ricoh print head for industrial production
CMYK W LC LM and varnish optional for glossy surface and high quality printing
3D Embossing effects printing technology available
Auto height detection technology to detect print media thickness automatically
Automatic anti-static design to avoid dust ink drops flying (optional)
Advanced printhead anti-crash system to avoid the risk of a collision between printer carriage and materia
CMYK W LC LM and varnish optional for glossy surface and high quality printing
3D Embossing effects printing technology available
Auto height detection technology to detect print media thickness automatically
Automatic anti-static design to avoid dust ink drops flying (optional)
Advanced printhead anti-crash system to avoid the risk of a collision between printer carriage and materia
Details Images
Adopting gray level Ricoh stainless steel internal heating industry head which has high performance in speed and resolution. It is suitable for long-time working, 24 hours running.
Adopting dual-level precision screw rod and imported Panasonic servo synchronous motors, ensure the screws rod on the both sides of Y axis synchronous running.
The safety anti-crash sensor can detect the media circumstance beforehand and protect the print heads from a crush hazard. After that, you can resume printer, which will help you save media.
The printer automatically measure with senses distance nozzle and media, which eliminate the procedure that we measure thickness by ourselves.
Automatic anti-static design to avoid dusk ink drops flying, which reduce the ink over spray caused by static, improve the print quality on some substrate.
Registration pin can be equiped with vacuum table that help to keep object in place easily at the zero position.
Printing Samples
Company Profile
Linyi Win-Win Machinery Co., Ltd is founded in 2009 in Linyi City, Shandong province, China. We are professional manufacturer of UV printer for 9 years in China. Our factory occupies more than 20,000 square meters, with six professional production lines to support annually sales volume. There are professional R&D center and sales team for domestic and international sales, and after-sales service team for customers. Some agents and third-party after-sales service center to ensure timely service for our customers as well. We export our printers since 2012, with high quality, friendly service and competitive price, our printers are welcome in Asia, Europe, Australia and Africa etc.
As a professional manufacturer and exporter of UV flatbed printer in China, we have advanced manufacture center, stable parts supplier, consumables supplier and constantly updated technology department to provide excellent service and best price for our customers. OEM service is available. Our printers have been widely used to print on glass, ceramic tile, PVC ceiling, aluminum plastic board, wood, MDF board, metal panel, billboard, acrylic panel, paper board, foam board, PVC expansion board, corrugated cardboard, bamboo fiber board etc. And also for flexible materials such as PVC, canvas, leather, fabric and cylinder bottles etc.
As the market continues to expand, our machines have won widespread praise and recognition by our customers all over the world. We are looking for agents globally and welcome to work with us.
Our Exhibition&Team
FAQ
1.How long does the printing images will last outdoors and indoor?
The printing images can last at least 3 years outdoors, and more than 10 years indoor.
2.What is the cost of ink for printing on the materials?
Normally it is around 0.5-1usd per square meter for ink cost.
3.How about the stability and quality of the printing images?
This UV flatbed printer can used to print on most of medias with best quality, durability, best result.
4.How about the maintance and aftersales service?
Our engineer available service overseas, and we can provide remote control service and online service for customers. But costomer has to be responsible for the accommodation and transportation costs of the technical staff.
5.Are you a manufacturer or trade agent?
We are the manufacturer of UV flatbed printers.
6.Is there any guarantee for this printer?
Yes, we have guarantee for the printer. We provide 13 months warranty for all the electronic parts including the main board, driver board, control board, motor, etc, except the consumables, such as ink pump, printhead, ink filter, and slide block etc.
7.How can I install and start to use the printer?
Normally we will arrange technican for installation and training in your factory. or you can read the users' manual to understand the machine. If you need any help, our technician can help you via Teamviewer. Whenever you have questions to the machine, you can contact our technician or me directly.
8.Can I get supplies and wearing parts from you?
Yes, we provide all the wearing parts for our printers always and they are in stock.
9.How will you achieve the warranty?
If any electronics or a mechanical part is confirmed to be broken, Ntek should send the new part within 48hours by express like TNT, DHL, FEDEX .etc to the buyer. And the shipping cost should be born by the buyer.
10.What kinds of materials need premier before printing?
Glass, ceramic, metel, acrylic, marble etc
