Высокий соp полный инверторного типа моноблок использующий теплоту воздуха дом Отопление тепловой насос с передачей тепла от к система водоснабжения bomba
- Категория: >>>
- Поставщик: Power,World,Machinery,Equipment,Co.,LtdPower,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 403857.79 $* | 424050.12 $* |
| Aug-16-2025 | 400464.10 $* | 420487.90 $* |
| Jul-16-2025 | 335982.86 $* | 352781.22 $* |
| Jun-16-2025 | 393676.49 $* | 413360.4 $* |
| May-16-2025 | 342770.9 $* | 359909.61 $* |
| Apr-16-2025 | 386889.55 $* | 406233.13 $* |
| Mar-16-2025 | 383495.80 $* | 402670.83 $* |
| Feb-16-2025 | 380101.23 $* | 399106.58 $* |
| Jan-16-2025 | 376707.67 $* | 395542.42 $* |
Характеристики
Products Description
Power World ERP A+++ 8kw 13kw 18kw 23kw Full DC inverter Heat Pump for Heaing Cooling,DHW
1.Adopting R32 refrigerant and circulating heating method,is able to keep its energy efficiency high.
2.Best Selling Market: Global, especially in North & East Europe, North America,ect.
3.Ambient Temp of Using: Minus 25℃-43℃.
4.Max water temperature: 60℃
5.Certification: ISO9001,,CE, CB. ERP A+++ and ERP reports certified by TÜV,ect.
6.Use *Panasonic* Inverter Compressor for DC Inverter Air Source Heat Pump.
Power World Easylife Series adopts full inverter Panasonic twin-rotary compressor and inverter brushless motor. With this technology, users can enjoy a maximum level of comfort with the lowest costs.
The ERP energy label gives an indication of energy efficiency in products. A rating system of A to G is used to rate the
efficiency of products such as heat pumps. by TUV SUD, which is the highest rating available. This rating indicates that The new DC inverter heat pumps from Power World have been rated ERP A+++ our air source heat pumps have low energy consumption and a high coefficient with SCOP of 4.9 of performance (COP). The highly energy-efficient DC inverter heat pumps use more than 30% less energy than other air source heat pumps.
efficiency of products such as heat pumps. by TUV SUD, which is the highest rating available. This rating indicates that The new DC inverter heat pumps from Power World have been rated ERP A+++ our air source heat pumps have low energy consumption and a high coefficient with SCOP of 4.9 of performance (COP). The highly energy-efficient DC inverter heat pumps use more than 30% less energy than other air source heat pumps.
Before the indoor temperature reaches the set value, the Panasonic rotary compressor delivers high levels of efficiency, enabling the unit to operate at high frequency so that it can heat water or provide house heating/cooling at a faster speed.
5 Modes
Mode 1: Central Hot Water: Constant Temperature, Sufficient Water Volume, 24-hour Instant Supply.
Mode 2: Central Cooling: Water Cooled Air Conditioning, Soft Air Supply, Comfortable for Human Body.
Mode 3: Whole House Heating: Water Cycled Floor Heating,Well-distributed Heat Dissipation, Healthy & Energy Saving.
Mode 4: Hot Water + House Cooling: Meet the Requirements of Both Central Hot Water and Air Conditioning.
Mode 5: Hot Water + House Heating: Meet the Requirements of Both Central Hot Water and Room Heating.
1.With Panasonic rotary compressor and DC inverter brushless fans, our DC inverter heat pumps adopt new noise reduction measures so that the sound of the unit is controlled at a satisfactory level.
2.With the Cascade function, multiple heat pumps can be controlled at once for greater operating efficiency. The WIFI APP enables users to operate their units through a smart phone wherever and whenever they are.
3.Hidden screw design is very popular with European clients,the whole unit is very simple and beautiful.
3.Hidden screw design is very popular with European clients,the whole unit is very simple and beautiful.
PW030-DKZLRS-A
PW040-DKZLRS-A
(R32）
PW050-DKZLRS-A
PW060-DKZLRS-A
（R32)
Product model | PW030-DKZLRS-A | PW040-DKZLRS-A | PW050-DKZLRS-A | PW060-DKZLRS-A | |||||
Heating | Heating Capacity Range (kW) | 1.57~8.40 | 4.40~13.00 | 5.9~18.2 | 7.5~23.0 | ||||
Heating input Range (kW) | 0.32~1.87 | 0.90~3.02 | 1.20~4.11 | 1.53~5.23 | |||||
current Range (A) | 1.42~8.30 | 1.39~4.68 | 1.86~6.37 | 2.37~8.11 | |||||
COP Range | 4.49~4.91 | 4.30~4.90 | 4.43~4.92 | 4.40~4.90 | |||||
Cooling | Cooling capacity Range (kW) | 0.99~6.22 | 2.80~8.20 | 3.81~11.53 | 4.73~14.6 | ||||
Cooling input power(kW) | 0.29~2.18 | 0.85~3.31 | 1.11~4.05 | 1.39~5.14 | |||||
current Range (A) | 1.28~9.67 | 1.32~5.13 | 1.72~6.28 | 2.16~7.97 | |||||
EER Range | 2.85~3.41 | 2.48~3.29 | 2.85~3.43 | 2.84~3.40 | |||||
DHW | Heating capacity Range (kW) | 1.28~6.81 | 3.52~10.50 | 4.80~14.72 | 6.1~18.5 | ||||
Heating input Range (kW) | 0.31~2.13 | 0.88~3.39 | 1.17~4.60 | 1.53~5.97 | |||||
current Range (A) | 1.38~9.45 | 1.36~5.26 | 1.82~7.15 | 2.37~9.26 | |||||
COP Range | 3.2~4.1 | 3.1~4.0 | 3.2~4.1 | 3.1~4.0 | |||||
Refrigerant | R32 (GWP only 1/3 of R410a) | ||||||||
Power supply | 230V/1Ph/50-60Hz | 380V/3Ph/50-60Hz | |||||||
Working area | -25~43℃ | ||||||||
Compressor Brand | Panasonic DC Inverter Twin Rotary | ||||||||
Body size(W*D*H) (mm) | 970×475×835 | 1100×475×985 | 1050×480×1330 | 1050×480×1330 | |||||
Packing size(W*D*H)（carton） | 1028×520×974 | 1120×515×1108 | 1100×530×1470 | 1100×530×1470 | |||||
Packing size(W*D*H)（Polywood） | 1048×520×974 | 1140×515×1110 | 1120×530×1470 | 1120×530×1470 | |||||
Loading quantity (20GP/40GP/40HQ) | 44/88/88 | 44/88/88 | 22/42/42 | 22/42/42 | |||||
PF-030DC/E
(R410a)
PF-050DC/E
PF-050DC/NE
(R410a)
Product model | PF-030DC/E | PF-050DC/E | PF-050DC/NE | ||||
Cooling | Cooling capacity(kW) | 7.7 | 12.8 | 12.8 | |||
Cooling capacity Min / Max(kW) | 4.9/8.9 | 8.2/14.8 | 8.2/14.8 | ||||
Cooling input power(kW) | 2.6 | 4.2 | 4.2 | ||||
Cooling input power Min / Max (kW) | 1.5/3.7 | 2.5/6.0 | 2.5/6.0 | ||||
Rated current (A) | 12.7 | 20.5 | 8.4 | ||||
Current Min / Max (A) | 7.3/18.1 | 12.2/29.3 | 5.0/12.0 | ||||
EER | 2.96 | 3.05 | 3.05 | ||||
EER Min / Max | 2.41/3.27 | 2.47/3.28 | 2.47/3.28 | ||||
Heating | Heating capacity(kW) | 11.8 | 18.8 | 18.8 | |||
Heating capacity Min / Max (kW) | 7.4/15.9 | 11.7/23.5 | 11.7/23.5 | ||||
Heating input power(kW) | 2.64 | 4.2 | 4.2 | ||||
Heating input power Min / Max (kW) | 1.5/3.9 | 2.4/6.4 | 2.4/6.4 | ||||
Rated current (A) | 12.8 | 21 | 8.4 | ||||
Current Min / Max (A) | 7.5/19.3 | 11.7/30.5 | 4.8/12.8 | ||||
COP | 4.47 | 4.48 | 4.48 | ||||
COP Min / Max | 3.69/4.9 | 3.67/4.88 | 3.67/4.88 | ||||
DHW | Heating capacity(kW) | 9.5 | 15.4 | 15.4 | |||
Heating capacity Min / Max (kW) | 5.9/12.8 | 9.4/19.8 | 9.4/19.8 | ||||
Heating input power(kW) | 2.7 | 4.4 | 4.4 | ||||
Heating input power Min / Max (kW) | 1.5/4.2 | 2.4/6.8 | 2.4/6.8 | ||||
Rated current (A) | 13 | 22 | 8.8 | ||||
Current Min / Max (A) | 7.3/19.7 | 12.1/32.8 | 4.8/13.6 | ||||
COP | 3.52 | 3.50 | 3.50 | ||||
COP Min / Max | 3.05/3.93 | 2.91/3.92 | 2.91/3.92 | ||||
Refrigerant | R410A | ||||||
Power supply | 208~240V~/50Hz | 380~415V/3N~/50Hz | |||||
Working area | -30～43℃ | ||||||
Why Choose Us
Power World New Energy Technology Co.,Ltd.
Power World has a heat pump R&D center with a team of 20 engineersand four professional laboratories. Complying with ISO9001: 2008&ISO14001: 2004,all products get CE, CB (IEC) certificate and ERP Energy Label based on EN14825, EN14511,strictly according to latest EHPA requirement.
FAQ
Q1: Are you heat pump supplier of trading company or manufacturer ?
A1: We are R&D and manufacturer factory. With 300,000 sq meters modern factory in Shenzhen City & Dongguan City. with OEM service provided, MOQ> 20 Units.
A1: We are R&D and manufacturer factory. With 300,000 sq meters modern factory in Shenzhen City & Dongguan City. with OEM service provided, MOQ> 20 Units.
Q2: How long is your Heat Pump delivery time?
A2: Generally it is 1-5 working days if the goods are in stock. or it is 15-25 working days if the goods are not in stock, it is
according to quantity.
Q3: Do you also provide other kind of heat pump?
A3: ASHP of EVI(8KW-132KW) | SWIM POOL(2KW-150KW) I Domestic heat pump(80L-300L tank size),etc.
Q4: Wonder if you accept small orders?
A4: Do not worry. Feel free to contact us .in order to get more orders and give our clients more convener ,we accept small order.
Q5: Can you send products to my country?
A5: Sure, we can. If you do not have your own ship forwarder, we can help you.
Q6: Can you do OEM for me?
A6: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
Q7: What's your payment terms ?
A7: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q8: How can I place the order?
A8: First sign the PI,pay deposit,then we will arrange the production.After finished production need you pay balance. Finally we will ship the Goods.
Q9 When can I get the quotation ?
A9: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
A2: Generally it is 1-5 working days if the goods are in stock. or it is 15-25 working days if the goods are not in stock, it is
according to quantity.
Q3: Do you also provide other kind of heat pump?
A3: ASHP of EVI(8KW-132KW) | SWIM POOL(2KW-150KW) I Domestic heat pump(80L-300L tank size),etc.
Q4: Wonder if you accept small orders?
A4: Do not worry. Feel free to contact us .in order to get more orders and give our clients more convener ,we accept small order.
Q5: Can you send products to my country?
A5: Sure, we can. If you do not have your own ship forwarder, we can help you.
Q6: Can you do OEM for me?
A6: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
Q7: What's your payment terms ?
A7: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q8: How can I place the order?
A8: First sign the PI,pay deposit,then we will arrange the production.After finished production need you pay balance. Finally we will ship the Goods.
Q9 When can I get the quotation ?
A9: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
Looking Forward to Your Inquiry
Power World
email:marketing@powerworld-e.com
WhatsApp:+86-13763165244
Wechat: 13763165244
TEL:+86-0769-89979297
Website: www.powerworld-e.com
Add:Headquarters Add:No.24,the fourth industrial zone,HouTing Street,ShaJing Town,BaoAn District,Shenzhen China.
Fatory Add: No.32 Luxi 2nd Road,Xixi Street,Liaobu Town,Dongguan,China.
If you are interested in this product,please fill in the below and send us,we will reply you and also send you the latest product catalog and latest quotation within 1 hour.
↓↓↓↓↓
