Небольшая клейкая этикетка UHF RFID инкрустация для
- Категория: Other Access Control Products >>>
- Поставщик: Quanzhou,Jianghe,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.98 $* | 0.9 $* |
| Aug-17-2025 | 0.88 $* | 0.37 $* |
| Jul-17-2025 | 0.72 $* | 0.91 $* |
| Jun-17-2025 | 0.49 $* | 0.59 $* |
| May-17-2025 | 0.30 $* | 0.83 $* |
| Apr-17-2025 | 0.20 $* | 0.46 $* |
| Mar-17-2025 | 0.88 $* | 0.26 $* |
| Feb-17-2025 | 0.3 $* | 0.42 $* |
| Jan-17-2025 | 0.21 $* | 0.6 $* |
Характеристики
Products Description
INTRODUCE:
RFID tag is a kind of non-contact automatic identification technology. It can identify the target object and obtain the relevant
data through the radio frequency signal, and the identification work does not need manual intervention. RFID technology has the
advantages of waterproof, antimagnetic, high temperature resistance, long service life, large reading distance, data on the tag
can be encrypted, larger storage capacity, and easy change of stored information, which are not possessed by bar code Point.
data through the radio frequency signal, and the identification work does not need manual intervention. RFID technology has the
advantages of waterproof, antimagnetic, high temperature resistance, long service life, large reading distance, data on the tag
can be encrypted, larger storage capacity, and easy change of stored information, which are not possessed by bar code Point.
Different from traditional tags (such as bar code) or manual tags, the encoding, storage and read-write of RFID tags are stored in read-only or read-write format on integrated circuits; especially in read-write mode, the electronic tags are realized by wireless electronic transmission.
The prominent technical features of RFID tag are:
it can identify a single very specific object, not only one kind of object as bar code; it can read multiple objects at the same time, but bar code can only read one by one; it has a large amount of information stored; it can read data through external materials by using radio frequency, and bar code must be read in the material by laser or infrared Read information from the surface of the medium.
Physical Parameter | ||||||
8Size | 8mm ;9*12mm | |||||
Material | Coated paper or PVC | |||||
Color | White (Can be printed ); Inlay not with the printed layer | |||||
Weight | 1g | |||||
Packing | Antistatic packaging :1000pcs/roll ,5000pcs/roll or custom | |||||
Environmental Parameters | ||||||
Working Humidity | <95% | |||||
Working Temperature | -25 ~ 70℃ | |||||
Storage Temperature | -40 ~ 85℃ | |||||
Performance parameter | ||||||
Manufaturer/chip | Aline-H3 9613 ,J41 | 100um thickness | ||||
Basic material optional | Paper/PET/PP AD: AW3209, AW2150, AW1416 UPM: 04RP5X01H0 Or Customization | |||||
Antenna | Aluminum etching Al(10μm)+PET(50μm) | |||||
Protocol | ISO/IEC 18000-6C EPC Class1 Gen2 | |||||
IC Store area | EPC: 96bits TID: 32bits,Unique TID:64bits Passwordarea : 32bits User area: 512bits | Read and write Read only Read and write Read and write | ||||
Frequency | 860~960MHz | |||||
Reading distance | Depend on the reader and antenna | |||||
Operating Mode | Passive | |||||
IC life | 100,000 Programming cycles, 10years data retention | |||||
ESD Voltage Immunity | At most 2000v | Human being mode(HBM) | ||||
Details Images
Related Products
Widely Application
Company Profile
Workshop
Customer Feedback
FAQ
Question 1:
Question 3:
Question 6:
Is there stock for your products?
Answer: There is stock for different products in different periods. Please tell us what products you need, then we will check the stock for the products you need.
Question 2:
Question 2:
Do you offer samples?
Answer: For samples in stock, samples can be arranged directly and freely. For samples out of stock, new production needs to be arranged, and there is sample charge.
Answer: For samples in stock, samples can be arranged directly and freely. For samples out of stock, new production needs to be arranged, and there is sample charge.
Question 3:
How can the artwork be offered? Can do OEM and LOGO brand ?
Answer: Yes ,we support OEM and LOGO custom printing ,the Artwork can be sent to us by AI, or PSD,or CDR. But it has to be in vector graphics to ensure the quality of printing.
Question 4:
Answer: Yes ,we support OEM and LOGO custom printing ,the Artwork can be sent to us by AI, or PSD,or CDR. But it has to be in vector graphics to ensure the quality of printing.
Question 4:
What is MOQ? Can we order on pcs for the test ?
Answer: The MOQ is 1 pcs. For the 2.4G active tag usually different manufacture use Private communication protocol ,so if you need the samples to test ,also need to take the reader together can work well .
Question 5:
Answer: The MOQ is 1 pcs. For the 2.4G active tag usually different manufacture use Private communication protocol ,so if you need the samples to test ,also need to take the reader together can work well .
Question 5:
Can you do the whole solution including the hardware and software ?
Answer: Yes , we can . if you have the ability to docking/developing the software we will offer you the SDK /API /DEMO and communication protocol and user guide even the technical support . If you need we do the whole system ,we will done based on your requirement
Answer: Yes , we can . if you have the ability to docking/developing the software we will offer you the SDK /API /DEMO and communication protocol and user guide even the technical support . If you need we do the whole system ,we will done based on your requirement
Question 6:
What shipping way is adopted?
Answer: By Express, Air, Sea.Depends on clients' specific requirements and order quantity.
Question 7:
Answer: By Express, Air, Sea.Depends on clients' specific requirements and order quantity.
Question 7:
What is the lead time?
Answer: Generally, the shipping time is 3-5 working days if have stock here
Answer: Generally, the shipping time is 3-5 working days if have stock here
The production time is different indifferent periods for different orders. Please consult us according to your specific requirements of your order.
Question 8:
Question 8:
What payment do you adopt?
Answer: Western Union, Money Gram TT, Paypal. Paypal is just accepted for small amount.
Answer: Western Union, Money Gram TT, Paypal. Paypal is just accepted for small amount.
