Products Description




Product introduction
It is suitable for measuring the resistance value of variousinsulating materials and the insulation resistance of transformers,motors,cables and electrical equipment.




Specification


Function
Insulation resistance test, voltage test
Base conditions
23°C±5°C,below 75%rh
Rated Voltage(V)
100;250;500;1000;2500
Test Voltage(V)
Rated voltage x (1±10%)
Insulation Resistance Range
0.01MΩ-200GΩ Accuracy: ±3%rdg±5dgt
Insulation Resistance Resolution
0.01MΩ
DC Voltage Range
0-1000V
DC Voltage Resolution
0.1V
AC Voltage Range
0-750V
AC Voltage Resolution
0.1V
Output short-circuit Current
≥2mA (2500V)
Absorption Ratio and Polarization Index Measurement
Have
Power Supply
1.5V (LR14) Alkaline Battery 6 Section
Backlight
Controllable gray screen backlight, suitable to use in dim place
Display mode
4-bit large LCD display, gray screen backlight
LCD Display Size
108mm×65mm
Meter Dimension
L/W/H: 240mm×188mmx85mm
Test Line
High voltage test line red 1 meter, black 1 meter, green line 1 meter
Data Storage
500 groups, "FULL" symbol indicates that storage is full
Data Review
Data review function: "MR" symbol display
Overflow Display
Exceed measurement range overflow function: “OL ” symbol display
Alarm Function
Alarm when the measured value exceeds the alarm setting value
Power Consumption
Standby 40 mA Max (backlight off)
turn on backlight: 43 mA Max
measure: 80 mA Max (backlight off)
Weight
1230g (including battery)
Battery Voltage
Insufficient battery voltage, showing low battery symbol
Automatic shut-down
automatic shutdown after 15 minutes boot
Insulation Resistance
≥ 50MΩ (1000V)
Pressure Resistance
AC 3kV/50Hz 1min
Working Temperature and Humidity
-10°C~50 °C; below 80% rh
Storage Temperature and Humidity
-15°C~55°C; below 90% rh
Suitable for Safety Regulations
IEC61010-1, IEC1010-2-31, IEC61557-1, 5, IEC60529 (IP54), pollution grade 2, CAT III 300V
