Характеристики
Product Description
Thermal CTP
CRON’s thermal CTP products meet the most stringent demands for print quality. High-quality imaging is achieved through extremely accurate dot formation, a tonal range of 1%-99%, and up to 2800 dpi resolution. All CRON CTP can be customized for newspaper,commercial, or even security applications with resolution options from 1200 to 9600 dpi.
UV CTP/CTcP
Our UV CTP products are designed to provide flexibility and quality for all offset printing applications. Its easily serviceable
platform and cost-efficient design, combined with comprehensive automation options, offer fast, productive UV plate production
across a wide range of formats from A3 to VLF
platform and cost-efficient design, combined with comprehensive automation options, offer fast, productive UV plate production
across a wide range of formats from A3 to VLF
Computer To Plate CTP | ||||||
Expose type | Internal Scanning | |||||
Laser type | I.R. Semi-conductor Diode | |||||
Max.Plate Size | 920x670mm | |||||
Min.Plate size | 470x360 | |||||
Plate type | thermal Plate | |||||
Plate thickness | 0.15mm | |||||
Resultion | 2540DPI | |||||
Repeatability | <0.01 | |||||
Speed | 3min/plate | |||||
Plate load and unlaod | Semi Automatic | |||||
Operate Envirment | Normal room 21-27℃，Humdity <100% | |||||
Main Features
USED Computer to plate CTP
1) The process software is supporting PS and PDF file which is generated by kinds of common use plate maker software like In design and Word and also other kinds of Image format file
2) RIP color separation make all kinds of image, diagram and characters during the computer plate making into the recordable bitmap information from the maker. This information can be made as CMYK with different precision which have the screening angle
2) RIP color separation make all kinds of image, diagram and characters during the computer plate making into the recordable bitmap information from the maker. This information can be made as CMYK with different precision which have the screening angle
3)The makeup process function make the image and the characters finish the makeup on the page after the RIP and also the folding hand process function can demarcate the page number and sequence according to the size of the paper automatically.So its convenience totally change the working pattern of the traditional makeup performance, to make the operation easy, convenient and fast so that the work efficiency is improved.
4) When the CIP3 is under the process of the ink amount preset, the RIP work on the page,in the mean time of the makeup performance, the layout printing ink information will be interpreted and keep in the PPF files and then transferred into the press by internet. The press controlled identify and proceed the ink preset automatically,so the rationality and accuracy of the ink area distribution of the press is enhanced greatly
Manufacturer | CRON |
Year of Build | 2015 |
Press Position | China |
Machine Condition Options | In store,In stock,We offer as owners,Excellent condition,Worked on single shift |
Work Experiences | Thermal plate |
The Last Operator´s Opinion | Machine is main printing press in company Always taken maximum care Well maintained |
Swan's Opinion | Perfect machine for smaller printer Second owner Machine from smaller printing house Very good printing results No damage on impression cylinders |
Swan's Service | We are ready for loading,transporting and installing. |
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Visa for visit China support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Packing & Delivery
Packaging | ||
Size | 2200x1820x1720mm two packages | |
Weight | 400kgs | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
