ZT-ZGB5000 тестер сопротивления
- Категория: Resistance Meters >>>
- Поставщик: Zhuhai,Hengtai,Electric,Power,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.71 $* | 0.28 $* |
| Aug-20-2025 | 0.7 $* | 0.23 $* |
| Jul-20-2025 | 0.72 $* | 0.59 $* |
| Jun-20-2025 | 0.65 $* | 0.7 $* |
| May-20-2025 | 0.9 $* | 0.39 $* |
| Apr-20-2025 | 0.56 $* | 0.94 $* |
| Mar-20-2025 | 0.80 $* | 0.94 $* |
| Feb-20-2025 | 0.78 $* | 0.57 $* |
| Jan-20-2025 | 0.22 $* | 0.85 $* |
Характеристики
Product Description
Brief introduction
Our company is in accordance with the Standard Specification of electric power. Special launch of large capacity, high anti-interference, stable performance intelligent insulation resistance double display tester, the power equipment insulation, absorption ratio, polarization index test, provide accurate judgment of prophase series insulation test.
Because the charge current will affect a large capacitive testing products for tested value, so we need large charging current. The charge ability is better, absorption ratio test value is more close to the true value. This instrument is short circuit current is greater than 3mA, to overcome the ordinary megger short-circuit current small, the test is not accurate, Susceptible to interference problems. The instrument adopts the real-time voltage and current sampling to do division, so in the process of testing, even if the voltage change, resistance of value calculated from Ohm's law is accurate. The instrument adopts the principle of combining digital and pointer, the multi gear output voltage, convenient use for old and new customers. Easy to carry, simple operation; with large capacity lithium ion rechargeable battery, AC-DC dual-use, and
an undervoltage tip and the battery overcharge protection. The instrument can automatically display the current time, save 200 sets of test data and Storage time, for the test personnel's work provide a great convenience . This instrument is a new type of intelligent instrument, is the best choice for power test insulation detection.
Because the charge current will affect a large capacitive testing products for tested value, so we need large charging current. The charge ability is better, absorption ratio test value is more close to the true value. This instrument is short circuit current is greater than 3mA, to overcome the ordinary megger short-circuit current small, the test is not accurate, Susceptible to interference problems. The instrument adopts the real-time voltage and current sampling to do division, so in the process of testing, even if the voltage change, resistance of value calculated from Ohm's law is accurate. The instrument adopts the principle of combining digital and pointer, the multi gear output voltage, convenient use for old and new customers. Easy to carry, simple operation; with large capacity lithium ion rechargeable battery, AC-DC dual-use, and
an undervoltage tip and the battery overcharge protection. The instrument can automatically display the current time, save 200 sets of test data and Storage time, for the test personnel's work provide a great convenience . This instrument is a new type of intelligent instrument, is the best choice for power test insulation detection.
Product Feature
High-voltage insulation resistance tester, with 5 range: 500V, 1000V, 2500V, 5000V, test up to 2TΩ.
* Strict accordance with the safety standards for design
* Insulation resistance range 2TΩ @ 5 kv
* Automatic display polarization index (PI), induced electric absorption test values than (DAR).
* Anti-jamming performance is superior, the interference current reaches 2 mA, still ensure accuracy of test instruments.
* Capacitive discharge rapidly, cable test, no need manual discharge, instruments and automatic discharge quickly.
* 2 methods for power: use of lithium ion batteries, battery life can be up to 6 hours (5000V @ 100MΩ).
* Insulation resistance simulation column.
* Strict accordance with the safety standards for design
* Insulation resistance range 2TΩ @ 5 kv
* Automatic display polarization index (PI), induced electric absorption test values than (DAR).
* Anti-jamming performance is superior, the interference current reaches 2 mA, still ensure accuracy of test instruments.
* Capacitive discharge rapidly, cable test, no need manual discharge, instruments and automatic discharge quickly.
* 2 methods for power: use of lithium ion batteries, battery life can be up to 6 hours (5000V @ 100MΩ).
* Insulation resistance simulation column.
Specification
item | value |
Place of Origin | China |
Guangdong | |
Brand Name | Hengtai |
Model Number | ZT-ZGB5000 |
Display Type | Digital Only |
Measuring Range | |
Dimensions | 26cm x 20cm x 10cm |
AC Power | 220V±10%,50/60 HZ ,20 VA |
battery | 12.6V Lithium ion rechargeable battery |
Battery Life | 5000V@100M, 6 hour |
weight | 3kg |
Test voltage accuracy | the nominal value 100% to 110% |
Voltage measurement accuracy | 5%+3V |
Current test range | 10mA |
current measure precision | 5%+0.2nA |
short-circuit current | 3mA |
Capacitor discharge rate | from 5000V to 10V,2S/µF |
Insulation resistance testing range and accuracy （T:23±5ºC ，RH :45 – 75%） | ||||||||||
accuracy | range | 500V | 1000V | 2500V | 5000V | |||||
Unspecified | <100k | <100k | <100k | <100k | ||||||
5% | 100k-10G | 100k-20G | 100k-100G | 100k-100G | ||||||
20% | 100k-100G | 20G-200G | 100G-1T | 100G-1T | ||||||
Unspecified | > 100G | > 200G | > 1T | > 1T | ||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
ZHUHAI HENGTAI electric power technology Co.,ltd is a high-tech enterprise specializing in high-voltage power transmission and transformation test equipment R&D,production and operation.We sincerely hold the tenet of "quality first,customers supreme,honor commitment trustworthy".
Over the years,our company stays commitment R&D about electric power detection equipment and electric power automation,since its foundation,the company keeps living up to the belief of: "Create high-quality brand ,casting first-class enterprise image".Also,we make the "steady development,the best quality"as the core concept of the enterprise.While we are constantly strengthening the company's own R&D capabilities,learning from Europe and the United States leading technology and successful experience to enable enterprise to maintain a leading edge in technology and operations.It's certain that users are provided with "efficient,safe,innovative"services and technical support to provide customers with more satisfactory products. The company's main products are: high-voltage switch tester, loop resistance tester, transformer DC resistance tester, frequency conversion series resonance, transformer ratio tester, automatic dielectric loss tester, insulating oil dielectric strength tester, transformer comprehensive tester, DC high voltage generator, zinc oxide arrester live tester, intelligent cable fault tester and so on.
Talent is the foundation of an enterprise.The company has hired a group of experts and senior engineers with high theoretical engineering masters,doctors and field experience in power systems to strengthen the company's development to meet the needs of every user.Our products have passed the ISO 9001 international quality system certification and the provincial power research institute, the pilot institute of inspection and certification,and they are widely used in electric power, metallurgy, petrochemical, railway, research institutes, military industry and various types of large factories, mining enterprises, power equipment production enterprises.
Strict discipline, scientific management, standardized operation,we are sedulously improving and innovating in the field of power testing ,and we are deeply impressed by the quality,which makes our products have been widely appreciated and favored by our customers.
We will make unremitting efforts to provide new and old customers with better equipment and better service. Let us work hand in hand with you to contribute to the construction and maintenance of the national grid.
Over the years,our company stays commitment R&D about electric power detection equipment and electric power automation,since its foundation,the company keeps living up to the belief of: "Create high-quality brand ,casting first-class enterprise image".Also,we make the "steady development,the best quality"as the core concept of the enterprise.While we are constantly strengthening the company's own R&D capabilities,learning from Europe and the United States leading technology and successful experience to enable enterprise to maintain a leading edge in technology and operations.It's certain that users are provided with "efficient,safe,innovative"services and technical support to provide customers with more satisfactory products. The company's main products are: high-voltage switch tester, loop resistance tester, transformer DC resistance tester, frequency conversion series resonance, transformer ratio tester, automatic dielectric loss tester, insulating oil dielectric strength tester, transformer comprehensive tester, DC high voltage generator, zinc oxide arrester live tester, intelligent cable fault tester and so on.
Talent is the foundation of an enterprise.The company has hired a group of experts and senior engineers with high theoretical engineering masters,doctors and field experience in power systems to strengthen the company's development to meet the needs of every user.Our products have passed the ISO 9001 international quality system certification and the provincial power research institute, the pilot institute of inspection and certification,and they are widely used in electric power, metallurgy, petrochemical, railway, research institutes, military industry and various types of large factories, mining enterprises, power equipment production enterprises.
Strict discipline, scientific management, standardized operation,we are sedulously improving and innovating in the field of power testing ,and we are deeply impressed by the quality,which makes our products have been widely appreciated and favored by our customers.
We will make unremitting efforts to provide new and old customers with better equipment and better service. Let us work hand in hand with you to contribute to the construction and maintenance of the national grid.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2004,sell to Domestic Market(90.00%),Southeast Asia(5.00%),Africa(3.00%),South America(2.00%). There are total about null people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Switching mechanical characteristics,Series Pressure Resistance Test Device,Transformer DC resistance tester,Insulation resistance tester,AC DC test Transformer
4. why should you buy from us not from other suppliers?
Zhuhai Hengtai Power Technology Co. Ltd. has been engaged in the production of high-pressure testing equipment in China for many years. it was named "Guangdong Provincial Contract Honor Credit Company." in China. Advanced equipment technology, lightweight
5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:null;
Accepted Payment Type: T/T,L/C,Credit Card,Cash;
Language Spoken:English,Chinese
We are based in Guangdong, China, start from 2004,sell to Domestic Market(90.00%),Southeast Asia(5.00%),Africa(3.00%),South America(2.00%). There are total about null people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Switching mechanical characteristics,Series Pressure Resistance Test Device,Transformer DC resistance tester,Insulation resistance tester,AC DC test Transformer
4. why should you buy from us not from other suppliers?
Zhuhai Hengtai Power Technology Co. Ltd. has been engaged in the production of high-pressure testing equipment in China for many years. it was named "Guangdong Provincial Contract Honor Credit Company." in China. Advanced equipment technology, lightweight
5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:null;
Accepted Payment Type: T/T,L/C,Credit Card,Cash;
Language Spoken:English,Chinese
