Q22HD-15,Q22HD-15pneumatic control valve,Q22HD-15Water valve

To understandQ22HD-15,Q22HD-15pneumatic control valve,Q22HDWater valveThe price of this product,For detailed information such as parameters, please find Fenghua Lihui Automation Equipment Co., Ltd.,This product produced by our company is cost-effective,Good quality.It is incomparable to the quality of ordinary products..

This one from our companyQ22HD-15,Q22HD-15pneumatic control valve,Q22HD-15The quality of the water valve is very reliable.Excellent performance.It is an ideal fluid pneumatic control valve.This valve is normally controlled by a two-position five-way valve.,Of course, it can also be controlled by two tee valve.Superior performance,The quality is very reliable.Very convenient to use.This product of our company is an ideal product.

Q22HD-15,Q22HD-15pneumatic control valve,Q22HD-15Water valve as a fluid pneumatic control valve,Excellent quality,Superior performance.It is an ideal product.Q22HD-15,Q22HD-15pneumatic control valve,Q22HD-15The water valve is generally controlled by a two-position five-way valve.,Of course, it can also be controlled by two tee valve.Very convenient to use,The structure is very reasonable and reliable..This product is actually a combination of cylinder and water valve..As long as the upper cylinder is controlled,This product can be easily controlled..Q22HD-15,Q22HD-15pneumatic control valve,Q22HD-15The sealing material inside the water valve can be high temperature resistant.,Corrosion resistance,Special material for oxidation resistance,Excellent quality.



Brief Introduction
Q22HD-15,Q22HD-15pneumatic control valve,Q22HD-15Water valve working medium Air,Water,Oil,Liquefied gas,Light dynamic viscosity fluid Working pressure 0.2~0.6Mpa Medium and ambient temperature 5~50℃ flower factorKVValue 4 5 10 25 40

Q22HD-15,Q22HD-15pneumatic control valve,Q22HD-15Detailed introduction of water valve
Q22HD-15,Q22HD-15pneumatic control valve,Q22HD-15Water valve Detailed description: Product Model: Q22HD-50 Product Name:Q22HDSeries fluid pneumatic control valve Q22HDpneumatic control valve Q22HDWater Valve Product Description This valve is actuating pressure low,High closing sensitivity,Good sealing performance,Any import and export direction. Type cut-off,Gate type,Dual-position traffic adjustable and other structures.Now extensive Application in food,Medicine,Industrial,Washing,Petrochemical,Metallurgy,Spraying,Vehicle and other machines Mechanical equipment. Parameter Model Q22HD-15 Q22HD-20 Q22HD-25 Q22HD-35 Q22HD-40 Q22HD-50 Nominal diameter 15 20 25 40 50 Pipe Thread G1/2” G3/4” G1” G11/4” G11/2” G2” Working medium Air,Water,Oil,Liquefied gas,Light dynamic viscosity fluid Working pressure 0.2~0.6Mpa Medium and ambient temperature 5~50℃ flower factorKVValue 4 5 10 25 40 Model A B C D H M Q22HD-15 46 26 φ30 G1/2” 96 G1/8” Q22HD-20 54 32 φ37 G3/4” 107 G1/8” Q22HD-25 66 34 φ37 G1” 118 G1/8” Q22HD-35 80 53 φ65 G11/4” 162 G1/8” Q22HD-40 80 53.6 φ65 G11/2” 162 G1/8” Q22HD-50 105 66 φ78 G2” 180 G1/4”
Product related keywords: Q22HD-15,Q22HD-15pneumatic control valve,Q22HD-15Water valve
