9YQ-2200S машина для прессования квадратных

Цена:24 300,00 $*

Количество:

Products Description

Product Paramenters

Item	Design Value
Model Name	9YQ-2200S Square Baler
Hitch Type	Trailed
Bale Size
Length (mm)	300～1300 Adjustable
Section Size(mm)	360x460
Weight（Kg）	10～35
Pick Up
Pick Up Width (mm)	2220
Structure Type	Hammer Claw
Overload Protection	Over-drive Clutch
Baling Room
Section size of compression chamber （W×H）(mm)	460x360
Piston Frequency (times)	100
Piston Stroke(mm)	550
Bale Density Control	Spring loaded density control
Feeding System
Feed Inlet Width (mm)	440
Structure Type	Shift fork feeding mechanism
Number of Feeding Forks	5
Overload Protection	Safe cut bolt
Knotting System
Number of Knotters	2
Knotter Type	D型
Overload Protection	Safe cut bolt
Rope Box Capacity	6/10
Bundle Rate	≥98%
Bale Density(kg/m3)	≥100
Dimensions
Working Status (LxWxH)(mm)	6450x3170x1870
Tire Specifications	10/75-15.3
Productivity（t/h)	3～6
Weight（kg)	3700
Motor Power(Kw)	≥88.2
Tractor Output Shaft Speed（r/min）	720
Lighting System	Backlight
Surveillance System	Knotter monitoring, tail and bale out monitoring
Bundling Counter	Electronic, LCD counter (can be cleared, the total is accumulated)
