300 кг 500 800 1000 2000 гидравлический настенный небольшой грузовой подъемник для
- Категория: Lift Tables >>>
- Поставщик: Qingdao,Eterlift,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 809.47 $* | 849.39 $* |
| Aug-20-2025 | 802.46 $* | 842.91 $* |
| Jul-20-2025 | 673.95 $* | 707.83 $* |
| Jun-20-2025 | 789.97 $* | 828.87 $* |
| May-20-2025 | 687.63 $* | 721.91 $* |
| Apr-20-2025 | 775.58 $* | 814.10 $* |
| Mar-20-2025 | 768.63 $* | 806.63 $* |
| Feb-20-2025 | 762.57 $* | 800.12 $* |
| Jan-20-2025 | 755.83 $* | 793.36 $* |
Характеристики
Freight elevator description
1. Strong carrying capacity, realizing multi-point control, interactive interlocking of upper and lower floors, to achieve safe use;
2. The lifting height is large, and the side-mounted oil cylinder or the double-test oil cylinder is used, which is stable in operation, no noise, easy to maintain, and has a long service life;
3. Manual lowering and emergency stop button after power failure, convenient, fast and practical;
4. The depth of the pit is generally 15cm-30cm, and the height of the top layer is not limited, which can be customized according to the site environment;
5. The floor door can be penetrated, and the inside and outside of the workshop can be opened mutually, which is convenient and saves space;
6. Especially suitable for 2-5 storey steel structure workshops, both internal and external;
7. Electrical components can be selected from brands such as Delixi, Chint, Shanghai People's Electric, Schneider from France, Siemens from Germany. In addition to the safety devices of traditional traction elevators, hydraulic elevators also include:
8. Relief valve: can prevent the system pressure from being too high during upward movement
9. Emergency manual valve: When the power fails, the car can be lowered to the nearest floor to open the door.
10. Manual pump: When the system fails, the manual pump can be operated to pump high-pressure oil to make the car rise to the nearest floor position;
2. The lifting height is large, and the side-mounted oil cylinder or the double-test oil cylinder is used, which is stable in operation, no noise, easy to maintain, and has a long service life;
3. Manual lowering and emergency stop button after power failure, convenient, fast and practical;
4. The depth of the pit is generally 15cm-30cm, and the height of the top layer is not limited, which can be customized according to the site environment;
5. The floor door can be penetrated, and the inside and outside of the workshop can be opened mutually, which is convenient and saves space;
6. Especially suitable for 2-5 storey steel structure workshops, both internal and external;
7. Electrical components can be selected from brands such as Delixi, Chint, Shanghai People's Electric, Schneider from France, Siemens from Germany. In addition to the safety devices of traditional traction elevators, hydraulic elevators also include:
8. Relief valve: can prevent the system pressure from being too high during upward movement
9. Emergency manual valve: When the power fails, the car can be lowered to the nearest floor to open the door.
10. Manual pump: When the system fails, the manual pump can be operated to pump high-pressure oil to make the car rise to the nearest floor position;
Model: | ELC |
Load capacity: | 150kg-3T |
Platform size : | customizable |
Max Lifting height : | customizable |
Self height: | ≤120mm |
Platform Material: | 100*50*4mm rectangular tube + 3mm checkered plate Q345B |
Guide Rails Height : | 4200mm |
Guide Rails thickness: | 300mm |
Guardrail Height : | 1000mm |
Guide Rails Material: | 100*100*7H |
Hydraulic Cylinders: | Diameter 70mm*1 |
Pump Motor: | 2.2kw |
Lifting Chains: | 16A |
Safety Rope: | Diameter 10mm |
