Create a moisture-resistant seal in applications where temperatures reach up to 450° F. An adhesive lining melts when the tubing is heated and bonds to the underlying surface, creating a water-resistant seal. Made of PTFE, it also resists abrasion and chemicals. Choose tubing with a larger shrink ratio to create a tight seal over irregularly shaped objects.
Performance index
Tomato&Potato
Solubility
≥280℃
Working Temperature
-80℃-260℃
Dielectric constant (*) 50 Hz
2.1
Hardness
85
Corrosion effect on copper
No corrosion
Antibacterial, erosion resistant
Good
Toughness (bending, bending, tearing, etc)
Good
Tensile strength Mpa(kgf/cm)
20.5
Breakdown voltage (normal temperature)（kv/mm）
30
Appearance
Bright surface, no drawing and pitting, no impurities inside and outside the pipe
Axial shrinkage (diameter) (%)
≥5%
Extensibility（%）
200
Combustibility
VW-1
Resistance
Wear resistance, acid and alkali resistance, anti impregnation, anti mold, corona discharge, resistant to industrial solvents, external mechanical damage, oil and special liquids
Environment protection
It is harmless to human body and environment, and conforms to Rosh standard
Details Images
Datasheet
Shrinkage ratio of 4 :1
Specifications
mm
Inner diameter before shrinkage
Inner diameter after complete shrinkage
Shrunken inner diameter
Thin
Thickness
Φ1.5
1.5±0.2
0.05
0.1
0.40±0.1
Φ2.0
2.0±0.2
0.05
0.12
0.50±0.1
Φ3.0
3.0±0.2
0.05
0.12
1.7±0.1
Φ4.5
4.5±0.2
0.05
0.12
1.2±0.1
Φ6.0
6.0±0.2
0.12
0.12
1.5±0.1
Φ7.0
7.0±0.2
0.12
0.15
2.8±0.1
Shrinkage ratio of 1.7 :1
Size mm
I.D(mm/ich)
Before shrink
Wall thickness
After shrunk
Wall thickness
Φ0.5
0.7±0.2
0.028
≤0.40
0.015
Φ1.0
1.0±0.2
0.039
≤0.50
0.018
Φ1.5
1.5±0.2
0.059
≤0.90
0.021
Φ2.0
2.0±0.2
0.079
≤1.30
0.026
Φ2.5
2.5±0.2
0.098
≤1.50
0.032
Φ3.0
3.0±0.2
0118
≤1.80
0.038
Φ3.5
3.5±0.2
0.138
≤2.0
0.046
Φ4.0
4.0±0.2
0.157
≤2.5
0.058
Φ4.5
4.5±0.3
0.177
≤2.8
0.072
Φ5.0
5.0±0.3
0.197
≤3.0
0.091
Φ6.0
6.0±0.3
0.236
≤3.8
0.112
Φ7.0
7.0±0.3
0.276
≤4.0
0.139
Φ8.0
8.0±0.3
0.315
≤4.8
0.174
Φ9.0
9.0±0.3
0.354
≤5.0
0.218
Φ10.0
10.0±0.3
0.394
≤6.0
0.273
Φ12.0
12.0±0.3
0.472
≤7.0
0.342
Product Usage
Application
Widely used in electronics, computer, electric heating, aviation, military, communications and other important science and technology industries,
such as micro transformer, special sensors, artificial blood vessels
