Медицинский эндоскоп портативная система камеры с кабелем цистоскопической ENT ветеринарный
- Категория: >>>
- Поставщик: Shanghai,Shiyin,Import,And,Export,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.40 $* | 0.35 $* |
| Aug-16-2025 | 0.99 $* | 0.4 $* |
| Jul-16-2025 | 0.23 $* | 0.21 $* |
| Jun-16-2025 | 0.74 $* | 0.94 $* |
| May-16-2025 | 0.87 $* | 0.9 $* |
| Apr-16-2025 | 0.65 $* | 0.99 $* |
| Mar-16-2025 | 0.76 $* | 0.89 $* |
| Feb-16-2025 | 0.50 $* | 0.95 $* |
| Jan-16-2025 | 0.40 $* | 0.52 $* |
Характеристики
Products Description
Endoscopy Camera | DVI,SDI,CVBS,DP,VGA,USB | |
Image sensor | 1/2.8 CMOS | |
Brightness | ODS adjustable | |
Horizontal resolution | 1200TVL | |
Scanning frequency | N:60HZ P:60HZ | |
Surface temperatures | ≤60℃ | |
LED Light Source | ||
Light source | LED light | |
Input power | 100VA | |
Color temperature | 6000±500K | |
Working life | ＞40,000hs | |
HD Video Recorder | ||
Recording format | MP4 | |
Input signal | HDMI, CVBS | |
Output signal | HDMI | |
Application：
SY-GW901 can be used for arthroscopy, ENT, PTED(percutaneous transforaminal endoscopic discectomy), cystoscope, percutaneous nephroscope, ventriculoscope, ductoscope, hysteroscopy, proctoscope, sigmoidoscope, urology resectoscope, plastic surgery endoscope, laparoscope, ductoscopy, breast implant endoscope, thoracoscopy, fiber nasopharyngoscope, fiber choledochoscopy, fber bronchoscope, fiber ureteroscope, APP hernia repair, lacrimal passage, minimally invasive varicose veins, etc.
Product material：
1. Our endoscope camera system use 304 stainless steel, brushed metal which contributes to cleaning, disinfection and maintenance. Color of machine appearance wont change for long-term use.
2. Set screws use stainless steel material, so screws wont rust off and cause electrical short which extends service life of machine.
3. Baseboard of inner circuit board uses simple brass and protection cover, which is effective protection to antijamming of circuit and ground connection.
4. All signal cables use double-shielded, enhanced antijamming material which guarantee the antijamming capacity and long working life. The signal cable can stand 50,000 times bend by testing.
2. Set screws use stainless steel material, so screws wont rust off and cause electrical short which extends service life of machine.
3. Baseboard of inner circuit board uses simple brass and protection cover, which is effective protection to antijamming of circuit and ground connection.
4. All signal cables use double-shielded, enhanced antijamming material which guarantee the antijamming capacity and long working life. The signal cable can stand 50,000 times bend by testing.
Product advantages：
1. Intelligent digital full HD 1200lines HD-1080P,
Effective pixels is 1920(H)*1080(V).
2. Full intelligent automatic white balance with one click(White balance and freeze buttons on the camera head)
3. 5”touch LCD screen, wear-resistant, scratch resistant, fastness, quick-witted.
Effective pixels is 1920(H)*1080(V).
2. Full intelligent automatic white balance with one click(White balance and freeze buttons on the camera head)
3. 5”touch LCD screen, wear-resistant, scratch resistant, fastness, quick-witted.
4. Solving electromagnetic interference of energy platform during operation ( such as ultrasonic knife, plasma knife,
electrosurgical unit, etc.)
electrosurgical unit, etc.)
5. Extinction speed is less than 0.2s, which can solve the operation delay of surgical images and reduce visual fatigue.
6. Brightness, sharpness, freeze, d-zoom, language, rs485, reset, etc, all these can be operated accordingly.
6. Brightness, sharpness, freeze, d-zoom, language, rs485, reset, etc, all these can be operated accordingly.
7. High brightness is comparable to 350W traditional xenon light source, could be used for all rigid endoscope surgery without any
problem.
problem.
8. Light source is customized connector, it accepts fiber light guides with active areas ranging from 3 mm to 10 mm diameter.
9. Wide range power from 100-240V/AC; 50/60 Hz.
9. Wide range power from 100-240V/AC; 50/60 Hz.
Accessory 1：Power Line
Accessory 2：BNC
Accessory 3：VGA
Accessory 4：HDMI-DVI
Accessory 5：Fiber cable
Accessory 6：Fuse
Company Profile
Shanghai Shiyin Photoelectric Instrument Co., Ltd.
Shanghai Shiyin Photoelectric Instrument Co., Ltd. was established in 2009,located in Shanghai Nanhui Industrial Park. It is a high-tech manufacturing enterprise engaged in the research, development, production, sales and service of medical HD endoscope camera system.The company specializes in the production of intelligent dual-mode 3D endoscope camera system, 4K UHD endoscope camera system, digital Full HD endoscope camera system, endoscope remote control system, gas insufflator, irrigation pump, medical monitors, medical LED cold light source, instruments and other general-purpose minimally invasive solutions, which can fully meet the needs of customers in clinical departments.
SHREK BUSINESS EXPANSION
We regularly participates in medical equipment exhibitions at home and abroad, and establishes strategic partnerships with many domestic and municipal medical industry associations to comprehensively serve business development and create core values for partners.
SHREK PARTNER
SHREK products have been widely recognized by customers in medical institutions in China, Germany, the United States, South Africa, Poland, Ukraine, Egypt, Brazil, France, Spain and other countries.
Our Advantages
1.GOOD SERVICE
We provide professional operation training, the first time response, the equipment enjoys 1-3 years warranty!
2.QUALITY ASSURANCE
We have strict quality control procedures and systems！
3.FACTORY ADVANTAGE
Factory price, sufficient inventory of regular products, provide OEM service.
4.RICH EXPERIENCE
More than 19 years of production experience.Our equipment can meet various types of minimally invasive surgery such as laparoscopy, hysteroscope, arthroscopy,ENT, urology,etc.
Packing & Delivery
