SEMV-400 система видеоэндоскопии Olympus по заводской

Item

Video Colonoscope

Video Gastroscope

Diameter of distal- end

Φ13.0mm

Φ9.8mm

Diameter of insert tube

Φ12.8mm

Φ9.6mm

Clamp aperture

Φ 3.7mm

Φ2.8mm

Working length

1335mm

1030 mm

Total length

1635mm

1330 mm

View of field

140 º

Depth of view

3-100mm

Resolution

Sony 440,000 Pixels high resolution Photosensitive CCD

Tip deflection

up 180° down 180° L/R 160°

up 210° down 90° L/R 100°

 Remark

We can provide OEM service, technical details can be customized.

Lamp : LED light (80W white)

Power: 220-240V; 50-60HZ

Illuminance : ≥200,000 lx

Color temperature : ≥5300K

Video signal output: 2 CVBS,S-Video

Sharpness adjustment :0-30 grade

Withe balance : Auto white balance/ Manually white balance

Gain function : 1-3 grade

Electronic shutter :Auto-shutter ,Manual shutter 10 steps can be adjustment.

 Air pump pressure : 30-60Mpk,

Metering mode :Peck metering / average metering, metering Area delineation

Lens optional :Manual lens, automatic lens, video lens ,

Left and right side Image position transformation

Air flow : 4-10 L/min

Package size :50.5*46*20cm (G.W.:7.34kgs)

Main Function:

DSP -digital image processor , color , brightness , Contrast 0-100 grade can be adjustment .

Continuous 4 pcs Image frozen and playback function and saved in SD card directly

Black and white reverse function .

Digital widescreen and picture in picture function.

Remark : this machine support Rigid endoscopy connection
