High quality polymer granules machine fertilizer making machine granulation



Product Description


The granulator machine integrates multiple functions such as granulating, pelletizing and coating.Fluidized granulator machine is mainly used to make powder materials into granules. This kind of dryer has a wide range of applications, high work efficiency, and can bring high economic value.


1  2


_20210105110220
























































































































Model



3



5



15



30



60



120



200



300



500



Volume(L)



12



22



45



100



220



420



670



1000



1500



Steam Expenditure (KG/H)



15



23



42



70



141



211



282



366



451



Min Capacity(kg/h)


 1.54101530 80100 150250

Max Capacity(kg/h)



4.5



6



20



45



90



160



300



450



750



Steam



Pressure(MPa)



0.3-0.6



Consumption(m3/min)



15



23



42



70



141



211



282



366



451



Compressed air



Pressure(MPa)



0.6



Consumption(m3/min)



0.9



0.9



0.9



0.9



1.0



1.0



1.5



1.5



1.5



Temperature(°C)



0-120°C(Room temperature to 120°C)



Wind motor power(KW)



3



4



5.5



7.5



11



18.5



22



30



45



Noise(Decibel)



≤75dB (A)






The above is our technical data. We can also design and manufacture different varieties upon customer's request.





5





Application:



Phamaceutical industry: tablet, capsule, low sugar or no sugar granule of Chinese medicine.


Food stuff: cocoa, coffee, milkpowder, juice of granulate, flavoring and so on.


Other industries: peticide, feed chemical fertilizer, pigment, dyestuff and so on.



 4





Features:


1.Because of powder Granulation, the fluidity is improved and the dust is reduced;


2.Because of powder Granulation, its solving property is improved;


3.The mixing, Granulation and drying can be completed inone step inside the machine;


4.The operation of equipment is safe because the anti static filtering cloth is adapted;


5.The operating personnel can not be damaged if explosion take place because there is releasing hole.3





Company Information


Great Machinery Equipment Co., Ltd.Located in Henan, China,is an enterprise of industry and trade with a collection of scientific researching,manufacturing,selling and serving more than 10 years' history,which is specialized in product different drying equipment,fruit & vegetable processing equipment and other food processing equipment,etc.
