Specifications of Low Cost Nine Output Modes Electrosurgical Unit Bipolar for Hospital

Nine output modes of Low Cost Nine Output Modes Electrosurgical Unit Bipolar for Hospital
Mono cut Cutting: 350W (load 500)

Blend: 250W(load 500)

Blend: 200W(load 800)

Blend: 150W(load 800)

Mono Coag Soft Coag: 120W (load 500)

Jet Coag: 100W (Load 500)

Bipolar Cutting: 70W (load 200)

Bioplar Bipolar Coag: 70W (load 200)

The characteristics of each function of Low Cost Nine Output Modes Electrosurgical Unit Bipolar for Hospital:
1. Cutting: pure cutting, its effect is fine cutting, tissue surface fresh without scab;

2. Mixed cutting 1: The effect is slight coagulation effect in cutting.

3. Mixed cutting 2: The effect is to provide powerful coagulation effect while cutting.

4. Mixed cutting 3: The effect is to provide a good coagulation effect while cutting, which is suitable for use under endoscopy.

5. Coag1: It can be called soft electrocoagulation or point coagulation. It has a relatively deep coagulation layer and a relatively small scope of action. It can be used with endoscopy.

6. Coag2: can be called strong electrocoagulation, also known as surface coagulation, relatively fast coagulation, larger area of action;

7. Coag3: It can be called jet electrocoagulation. It can provide effective non-contact coagulation and can be used in combination with argon system.

8. Bipolar Coag 1: It can be called rapid bipolar electrocoagulation. It can achieve the effect of coagulation at the moment of start-up and reduce the rate of misoperation during operation.

9. Bipolar Coag 2: It can be called fine bipolar electrocoagulation. It can quickly achieve the effect of coagulation at the start-up time, automatically cut off the power output during tissue coagulation, achieve excellent coagulation effect, and effectively prevent tissue adhesion.
Product advantages of Low Cost Nine Output Modes Electrosurgical Unit Bipolar for Hospital
1 Unipolar and bipolar automatic conversion function

2 It has an independent endoscope output port and an intelligent conversion key. After startup, autoregulation enters the endoscopic mode.

3 Memory function of restarting output record on boot

4 High Definition Large Digital Display

5 It has the function of on-off automatic monitoring and automatic detection in work and error prompting.

6 It can work underwater, cooperate with argon system, endoscopy, hysteroscopy, etc.

7 With the contact quality detection system of the patient circuit electrode plate, real-time detection of contact between the electrode circuit and the patient's skin, once the contact area is reduced, the resistance increases to an unsafe level, the machine automatically stops output and alarms.

8 Design of panel control touch mode with different acousto-optic indication for output of three output power high-definition large digital display
Technical parameters of Low Cost Nine Output Modes Electrosurgical Unit Bipolar for Hospital
1. Environmental temperature range: 5 C~40 C; 2. Relative humidity range: <80;

3. Atmospheric pressure range: 86.0-106.0 kpa; 4. Power supply: 220V (+22V), 50Hz (+1);

5. Working frequency: 360-460 kHz; 6. Rated power of equipment: 880 VA+10%;

7. Type of equipment: CF

The power consumption of the whole machine is less than 1000VA. (Cutting function 300)

Transport and storage of Low Cost Nine Output Modes Electrosurgical Unit Bipolar for Hospital
(a) ambient temperature range: - 40 55 C;
(b) relative humidity range: < 93%;
(c) atmospheric pressure range: 500 hPa to 1060 hpa;
Scope of application: Suitable for cutting and coagulation of tissues in operation. Its precise power control technology can meet various surgical needs.
