Сварочный прут Tianjin bridge сварочный электрод целлюлозного типа E6010 E6011 от Bridge лидер продаж для

Сварочный прут Tianjin bridge сварочный электрод целлюлозного типа E6010 E6011 от Bridge лидер продаж для

Категория: Welding Rods >>>
Поставщик: Tianjin,Bridge,Group,Co.,Ltd.

Цена:237,85 ₽*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-19-2025	301.5 $*	307.81 $*
Jul-19-2025	244.17 $*	249.61 $*
Jun-19-2025	296.33 $*	302.48 $*
May-19-2025	294.29 $*	300.26 $*
Apr-19-2025	235.28 $*	240.89 $*
Mar-19-2025	289.30 $*	295.40 $*
Feb-19-2025	287.6 $*	293.91 $*
Jan-19-2025	284.32 $*	290.43 $*

Характеристики

E6010

E6010 AWS A5.1 E6010

Rutile- cellulosic sodium Type Electrode ISO 2560-B-E4310 A

GB/T 5117 E4310

Applications:

It is suitable for welding of low carbon steel structure as pipeline, shipbuilding and bridge etc.

Characteristics:

E6010 is a rutile-cellulosic sodium type electrode. Can be weld for all-position (especially for vertical-down position) with DC⁺ only. It have excellent welding performance as stable arc, little spatter, easy slag removal and reignition-ability etc. Better molten pool control, stronger arc force and deeper penetration at vertical-down position.

Attention:

1. In generally, don't need to re-dry the electrode before welding. When it be affected with damp, should be re-dry it at 70℃-90℃ for 1 hour.

2. The rust, oil, water and other impurities of the weld area must be removed before welding.

Welding Positions:

PA, PB, PC, PD, PE, PF, PG

Chemical Composition of All Weld Metal: (Wt. %)

Items	C	Mn	Si	S	P	Ni	Cr	Mo	V
Require-ments	≤0.20	≤1.20	≤1.00	≤0.035	≤0.040	≤0.30	≤0.20	≤0.30	≤0.08
Typical Results	0.09	0.42	0.15	0.020	0.025	0.030	0.035	0.005	0.004

Mechanical Properties of All Weld Metal:

Items	Rm/MPa	Rel/Rp_0.2 /MPa	A/%	KV₂ (-30℃) /J
Requirements	≥430	≥330	≥20	≥27
Typical Results	475	400	26	80

X-ray Radiographic Inspection:

Level Ⅱ

Typical Operating Procedures:(DC⁺)

Diameter (mm)	2.5	3.2	4.0	5.0
Length (mm)	300	350	400	400
Current (A)	50-80	60-100	100-140	140-180

--- PRODUCT DISPLAY ---

--- PRODUCT APPLICATION ---

Some of our products have been applied to overseas key projects.

Electrode, SAW wire and flux of 600MPa Grade & 800MPa Grade applied to hydro steel at Laos pumped storage power station E6010 cellulose electrode Applied to the Ghana TEMA pipeline project in Africa successfully. It breaks the monopoly of Bohler cellulose electrode and won the bidding of oil pipeline Ghana tank project.
