120 литровая Вибрирующая отделочная машина нового

Описание и отзывы

Трекер стоимости

Характеристики

120 liter Vibratory Finishing Machine New type

Product name	Grinding polishing machine
Application	Polishing
Usage	Polishing Surface
Function	Metal Surface Grinding Polishing
Type	Fully Automatic
Material	High Wear Resistant Material
Color	Customer Requirement



model	Power (kw)	Amplitude (mm)	Speed (r/min)	Weight (kg)	Size (mm)
60L	0.75	0.8-2	1450	70	650*650*650
80L	1.1	0.8-2	1450	90	900*900*880
100L	1.1	0.8-2	1450	100	900*900*880
150L	1.5/2.2	0.8-2	1450	200	1150*1150*950
200L	2.2/3.0	0.8-2	1450	300	1250*1250*1000
300L	3.7/5.0	0.8-2	1450	400	1350*1350*1100
400L	3.7/5.0	0.8-2	1450	550	1450*1450*1150
600L	5.5/7.5	0.8-2	1450	750	1880*1880*1400
800L	9	0.8-2	1450	800	1950*1950*1450
900L	11	0.8-2	1450	900	2150*2150*1500
1200L	15	0.8-2	1450	1100	2400*2400*1600





 Please click here >>> Contact us for more factory prices, shipping and discounts

1. Effectively remove burrs, burrs, flashes, edges, corners, rust, stains, oil stains, oxide scales and lines on the surface of the parts, so that the surface of the parts can achieve a certain degree of smoothness, smoothness and brightness.
Automatic operation can be realized, and the processing condition of the surface of the part can be spot-checked at any time. The flat-bottomed and straight-mouthed vibrating finishing machine is equipped with a discharge port and a water outlet, and the straight mouth with discharge and bends have the function of automatic separation of abrasives and products.
2. The vibrating container does not use the previous non-wear-resistant black rubber material, but uses a one-time injection molded high wear-resistant PU rubber (polyurethane) material, which increases the service life of the lining by more than 5 times, while avoiding mutual interaction between parts Collision and reduction of noise.
3. Three-phase motor with high performance vibration source is installed inside, and the adjustable range of amplitude is 0.3-10mm.
4. We can provide customers with process samples of product parts free of charge to determine the choice of reasonable and cost-effective grinding and finishing processes (including: equipment selection, grinding and finishing auxiliary materials, etc.), and provide life-long maintenance and Technical Support.
5. The above prices do not include freight and tax. If you need a 17% value-added tax invoice, you need to add 10 points. The freight varies from place to place, please contact the shopkeeper to inquire about the freight. You can manually fill in the freight when shooting online.
