Zoomlion ZAT3000 тяжелые подъемные машины вездеходный

Zoomlion ZAT3000 тяжелые подъемные машины вездеходный

Категория: Truck Cranes >>>
Поставщик: Oriemac,Machinery,&,Equipment,(Shanghai),Co.,Ltd.

Цена:519 000,00 $ - 560 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	617610.3 $*	648491.46 $*
Aug-20-2025	612420.25 $*	643041.57 $*
Jul-20-2025	513810.10 $*	539501.97 $*
Jun-20-2025	602040.36 $*	632142.79 $*
May-20-2025	524190.25 $*	550400.34 $*
Apr-20-2025	591660.90 $*	621243.1 $*
Mar-20-2025	586470.51 $*	615794.96 $*
Feb-20-2025	581280.89 $*	610344.43 $*
Jan-20-2025	576090.32 $*	604895.96 $*

Характеристики

ZOOMLION ZAC1500

Product Description

Strong performance Boom
The industry's longest five-section 42m "U" main boom, integrated lifting performance leading industry same tonnage products
Precise and smooth operation
The operation action is customized with professional slow function, the minimum stable speed of rotation is 0.1°/s, and the minimum stable speed of lifting is 2.5m/min, which satisfies the precise lifting operation;
SUV Travelling in the crane
The low-speed and high-torque transmission system for construction machinery has strong power and the maximum speed is 90km/h;
Meet the requirements of the G class, the driving pass is better.
Energy saving and environmental protection
Intelligent multi-power mode energy-saving system, the average fuel consumption of the operation is 3.0L/h, and the overall fuel economy is 20%;
Intelligent communication
The telematics platform moves the in-vehicle information to the remote and realizes all-round information management through the mobile app.

Item		Value		Remarks
Work performance	Max. rated lifting capacity kg	300000
	Max. load moment of basic boom kN.m	8750		At 7 m radius
	Max. lifting height of main boom m	80		The parameters do not include deflection of main boom and jib.
	Max. lifting height of jib m	112
Work speeds	Max. hoist rope speed (Main winch) m/min	113		At the 4^th layer
	Max. hoist rope speed (Auxiliary winch) m/min	56		At the 2^nd layer
	Boom extending time min	15		Affected by the temperature and engine RPM
	Boom derricking up time s	80
	Slewing speed r/min	0 - 1.3
Driving	Max. operating altitude m	2000
	Max. driving speed km/h	80
	Approach angle °	17.5
	Departure angle °	14
	Max. gradeability %	50
	Min. turning diameter m	24
	Min. ground clearance mm	415
	Limits for exhaust pollutants and smoke	Conform to related standards		GB3847-2005
	Oil consumption per hundred kilometers L	91
Mass	Deadweight in driving condition kg	54990
	Axle load kg	12000
Dimensions	Overall dimensions (L × W × H) mm	17752 × 3000 × 4000
	Outrigger spread (L) m	8.8
	Outrigger spread (W) m	8.8
	Main boom length m	15.4 – 80
	Boom angle °	-0.6 – 82
	Light jib length m	12 - 32		Combination lengths
	Heavy Jib length m	9 - 32		Combination lengths
	Offset °	0, 15, 30
Others	Y-shaped guying system	Equipped	Y-shaped guying system
